DESCRIPTION
X-300 MCM Compact is an Industrial-Robot from Graal Tech. It is built for Security, Surveying, Inspection. Key figures: 480 min runtime.
X-300 MCM Compact is Graal Tech's compact autonomous underwater vehicle for mine countermeasures (MCM) and other demanding maritime security operations, built on the 155 mm diameter X-300 platform. Beyond MCM it can be adapted for scientific research, marine biology studies, underwater inspections and search and rescue missions. It travels at 4 knots, runs 8 to 10 hours on a 1.2 kWh Li-ion battery and is rated to 300 m. It navigates with an Orientus inertial unit, EvoLogics USBL, GPS and dead reckoning, communicates by acoustic modem and Wi-Fi, and carries a 900/1800 kHz side-scan sonar.
FEATURES
- Compact AUV for mine countermeasures
- 155 mm diameter (X-300 platform)
- Speed 4 knots
- Endurance 8-10 h
- Li-ion 1.2 kWh
- Depth rating 300 m
- Orientus INS, EvoLogics USBL, GPS, dead reckoning
- Side-scan sonar 900/1800 kHz
- Acoustic modem and Wi-Fi
- Also for research, marine biology, inspection, search and rescue
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | W 155 mm |
|---|---|
| Mobility | |
| Movement Type | Aquatic |
| Speed | 7.42 km/h |
| Environment | Underwater to 300 m; coastal and harbour waters |
| Power | |
| Battery Life | 480 min |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | W 155 mm |
|---|---|
| Mobility | |
| Movement Type | Aquatic |
| Speed | 7.42 km/h |
| Environment | Underwater to 300 m; coastal and harbour waters |
| Power | |
| Battery Life | 480 min |
Images
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the X-300 MCM Compact?
X-300 MCM Compact is Graal Tech's compact autonomous underwater vehicle for mine countermeasures (MCM) and other demanding maritime security operations, built on the 155 mm diameter X-300 platform.
Who makes the X-300 MCM Compact?
The X-300 MCM Compact is made by Graal Tech, a robotics company based in Italy.
How much does the X-300 MCM Compact cost?
Graal Tech has not publicly announced pricing for the X-300 MCM Compact. You can enquire through RobotAIGeek for current pricing.
What is the X-300 MCM Compact used for?
The X-300 MCM Compact is designed for security, surveying, and inspection. It is used in defence and research settings.
How fast is the X-300 MCM Compact?
The X-300 MCM Compact can move at speeds of up to 7.42 km/h.
What is the battery life of the X-300 MCM Compact?
The X-300 MCM Compact runs for about 480 minutes on a charge.
