DESCRIPTION
LYON BOY is an Industrial-Robot from HITO Robotic System. It is built for Intralogistics, Lifting, Material-Handling. Key figures: 80 kg, 500 kg payload.
LYON BOY (model HT-VDSM-10/20) is HITO's compact lifting AMR for moving racks, carts and goods in factories and warehouses. It drives under a load, lifts it by up to 60 mm and carries up to 500 kg at up to 1.5 m/s, on a chassis of 750 x 500 x 285 mm weighing 80 kg. It can navigate by magnetic tape, optical, laser, visual or inertial guidance or a hybrid of these, with guidance accuracy of +/-10 mm, docking accuracy of +/-5 mm and stopping accuracy of +/-10 mm, and its safety sensors cover a 270-degree field. Fleets are dispatched by HITO's scheduling software, which links to WMS and MES systems.
FEATURES
- Lifting AMR, model HT-VDSM-10/20
- Load up to 500 kg
- lifting height 60 mm
- Speed up to 1.5 m/s
- 750 x 500 x 285 mm
- 80 kg
- Magnetic / optical / laser / visual / inertial / hybrid navigation
- Guidance +/-10 mm, docking +/-5 mm, stop +/-10 mm
- 270 deg safety protection
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 80 kg |
|---|---|
| Dimensions | L 750 mm × W 500 mm × H 285 mm |
| Payload | 500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Sensors | safety protection sensors (270 deg coverage) |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 80 kg |
|---|---|
| Dimensions | L 750 mm × W 500 mm × H 285 mm |
| Payload | 500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Sensors | safety protection sensors (270 deg coverage) |
Images
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the LYON BOY?
LYON BOY (model HT-VDSM-10/20) is HITO's compact lifting AMR for moving racks, carts and goods in factories and warehouses. It drives under a load, lifts it by up to 60 mm and carries up to 500 kg at up to 1.5 m/s, on a chassis of 750 x 500 x 285 mm weighing 80 kg.
Who makes the LYON BOY?
The LYON BOY is made by HITO Robotic System, a robotics company based in China.
How much does the LYON BOY cost?
HITO Robotic System has not publicly announced pricing for the LYON BOY. You can enquire through RobotAIGeek for current pricing.
What is the LYON BOY used for?
The LYON BOY is designed for intralogistics, lifting, material-handling, and transport. It is used in automotive, electronics, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the LYON BOY?
The LYON BOY has a payload capacity of 500 kg.
How much does the LYON BOY weigh?
The LYON BOY weighs 80 kg.
How fast is the LYON BOY?
The LYON BOY can move at speeds of up to 5.4 km/h.
