DESCRIPTION
The FF1200S is Grenzebach's automated forklift, built specifically around the Euro pallet. It lifts to about 1,200 mm and carries roughly 1,200 kg — up to 1,500 kg on request — so it handles the pallet work that would otherwise tie up a driver. It runs at up to 2 m/s and turns inside a 1,450 mm radius, which is what makes it usable in real aisles rather than purpose-built ones. Free contour navigation means no magnetic tape, reflectors or floor infrastructure to install, and no safety zones to mark out; two certified safety laser scanners cover the vehicle in shared traffic. Positioning is typically accurate to about plus or minus 15 mm. At 1,725 by 800 by 1,950 mm it is the tallest of the three Grenzebach AGVs, and the company sells it as a module that drops into an existing intralogistics setup — optionally with its drive-range monitoring and autonomous goods-carrier detection.
FEATURES
- Automated forklift AGV built for Euro pallets and similar goods carriers
- Payload approx. 1,200 kg, up to 1,500 kg on request
- Maximum lifting height approx. 1,200 mm
- Dimensions 1,725 x 800 x 1,950 mm (L/W/H)
- Speed up to 2 m/s
- Turning radius 1,450 mm
- Positioning accuracy approx. +/-15 mm typical
- Two certified safety laser scanners
- Free contour navigation — no safety areas or floor infrastructure to install
- Optional autonomous load-carrier detection and drive-range monitoring
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.73 m × W 800 mm × H 1.95 m |
|---|---|
| Payload | 1200 kg |
| Repeatability | ±15 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 2 km/h |
| Environment | Indoor factory and warehouse floors in shared traffic; no floor infrastructure required |
| Sensing & Compute | |
| Sensors | two certified safety laser scanners, contour-navigation sensing |
| Software / AI | Grenzebach fleet manager, warehouse control system, security manager and statistics |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.73 m × W 800 mm × H 1.95 m |
|---|---|
| Payload | 1200 kg |
| Repeatability | ±15 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 2 km/h |
| Environment | Indoor factory and warehouse floors in shared traffic; no floor infrastructure required |
| Sensing & Compute | |
| Sensors | two certified safety laser scanners, contour-navigation sensing |
| Software / AI | Grenzebach fleet manager, warehouse control system, security manager and statistics |
Images
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Grenzebach FF1200S?
The FF1200S is Grenzebach's automated forklift, built specifically around the Euro pallet. It lifts to about 1,200 mm and carries roughly 1,200 kg — up to 1,500 kg on request — so it handles the pallet work that would otherwise tie up a driver.
Who makes the Grenzebach FF1200S?
The Grenzebach FF1200S is made by Grenzebach, a robotics company based in Germany.
How much does the Grenzebach FF1200S cost?
Grenzebach has not publicly announced pricing for the Grenzebach FF1200S. You can enquire through RobotAIGeek for current pricing.
What is the Grenzebach FF1200S used for?
The Grenzebach FF1200S is designed for intralogistics, material-handling, and transport. It is used in automotive, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the Grenzebach FF1200S?
The Grenzebach FF1200S has a payload capacity of 1,200 kg.
How fast is the Grenzebach FF1200S?
The Grenzebach FF1200S can move at speeds of up to 2 km/h.
