DESCRIPTION
YMBot Type D2 is a Humanoid from Yunmu Intelligent Manufacturing. It is built for Assembly, Pick-and-place, Industrial assembly and handling. Key figures: 150 kg, 6 kg payload, 1000 mm reach, 22 degrees of freedom.
The YMBot Type D2 is the industrial upgrade of the Type D, and Yunmu is precise about what changed: it retains all of the Type D's functions but replaces the arms with a force-controlled version supporting hybrid force-position control, which is the difference between a robot that follows a path and one that can regulate how hard it presses. Everything else scales up with it. It is taller at 1,800 mm extended and folds to 1,400 mm, and heavier at about 150 kg, with a 1.5 m dual-arm span, 6 kg per arm and a 1 m dual-arm working radius. It also gains a lifting column with a 20 kg hoisting payload that runs silently, reverses and stops at any position. The chassis is two-wheel differential with autonomous charging, obstacle surmounting and slope climbing, and LiDAR mapping, navigation and obstacle avoidance, and it still moves at about 1.5 m/s. Yunmu describes the arms as embodied-intelligent, with human-like movements and genuine dual-arm collaboration.
FEATURES
- Retains all Type D functions with dual arms upgraded to a force-controlled version supporting hybrid force-position control
- 560 x 560 x 1,800 mm extended, folding to 560 x 560 x 1,400 mm
- approximately 150 kg
- maximum movement speed of approximately 1.5 m/s
- 1.5 m dual-arm span with a dual-arm working radius of 1 m or less
- 22 degrees of freedom excluding end effectors
- 6 kg single-arm payload
- 20 kg hoisting payload on a lifting mechanism offering mute operation, forward and reverse rotation and stopping at any position
- two driving wheels with two-wheel differential motion control, autonomous charging, obstacle surmounting and slope climbing
- LiDAR mapping, navigation and obstacle avoidance
- embodied intelligent dual arms with human-like movements and dual-arm collaboration.
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 150 kg |
|---|---|
| Dimensions | L 560 mm × W 560 mm × H 1.8 m |
| Payload | 6 kg |
| Reach | 1 m |
| Mobility | |
| Movement Type | Wheeled |
| Degrees of Freedom | 22 |
| Speed | 5.4 km/h |
| Manipulation | High |
| Actuators | Force-controlled dual arms with hybrid force-position control on a two-wheel differential chassis with a lifting column rated to 20 kg hoisting payload |
| Sensing & Compute | |
| Sensors | LiDAR |
| Software / AI | LiDAR mapping, navigation and obstacle avoidance; autonomous charging; dual-arm collaborative control |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 150 kg |
|---|---|
| Dimensions | L 560 mm × W 560 mm × H 1.8 m |
| Payload | 6 kg |
| Reach | 1 m |
| Mobility | |
| Movement Type | Wheeled |
| Degrees of Freedom | 22 |
| Speed | 5.4 km/h |
| Manipulation | High |
| Actuators | Force-controlled dual arms with hybrid force-position control on a two-wheel differential chassis with a lifting column rated to 20 kg hoisting payload |
| Sensing & Compute | |
| Sensors | LiDAR |
| Software / AI | LiDAR mapping, navigation and obstacle avoidance; autonomous charging; dual-arm collaborative control |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the YMBot Type D2?
The YMBot Type D2 is the industrial upgrade of the Type D, and Yunmu is precise about what changed: it retains all of the Type D's functions but replaces the arms with a force-controlled version supporting hybrid force-position control, which is the difference between a robot that follows a path and one that can regula…
Who makes the YMBot Type D2?
The YMBot Type D2 is made by Yunmu Intelligent Manufacturing, a robotics company based in China.
How much does the YMBot Type D2 cost?
Yunmu Intelligent Manufacturing has not publicly announced pricing for the YMBot Type D2. You can enquire through RobotAIGeek for current pricing.
What is the YMBot Type D2 used for?
The YMBot Type D2 is designed for assembly, pick-and-place, industrial assembly and handling, and force-controlled manipulation tasks. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the YMBot Type D2?
The YMBot Type D2 has a payload capacity of 6 kg and a reach of 1 m.
How much does the YMBot Type D2 weigh?
The YMBot Type D2 weighs 150 kg.
How fast is the YMBot Type D2?
The YMBot Type D2 can move at speeds of up to 5.4 km/h.
How many degrees of freedom does the YMBot Type D2 have?
The YMBot Type D2 has 22 degrees of freedom.
