DESCRIPTION
YL-250F is a Mobile-Robots from GE Creative. It is built for Intralogistics, Material-Handling, Transport. Key figures: 160 kg, 300 min runtime, 500 kg payload.
The YL-250F is a lift-up autonomous mobile robot for prepared-food and bento factories that carries heavy loads on pallets and racks - up to 500 kg on slopes of up to 3 degrees - into refrigerators and freezers as cold as -25 C without condensation. Like the YT-350F launched alongside it, it navigates by Visual SLAM using feature points, so it keeps working as people move around and the layout changes, and adds magnetic-tape AGV guidance for stops within +/-20 mm. Large wheels on a bogie-arm suspension let it cross slopes and elevator gaps, it rides elevators and passes automatic doors through standard RFA linkage, and it returns to its station to charge automatically. The 1,156 x 921 x 249 mm robot weighs 160 kg, lifts by 50 mm, travels at up to 50 m/min (3 km/h) and runs 4 to 5 hours; a lightweight 11.7 kg aluminium rack is available.
FEATURES
- Lift-up transport, lift +50 mm
- payload 500 kg (up to 3-degree slopes)
- Freezer and refrigerator use (-25 C) without condensation
- Visual SLAM
- magnetic-tape AGV hybrid
- stop accuracy +/-20 mm
- Large wheels with bogie-arm suspension for slopes and elevator gaps
- Elevator and automatic-door linkage (RFA standard)
- Automatic charging at station
- operating time 4-5 h
- Size 1,156 x 921 x 249 mm
- 160 kg
- max 50 m/min (3 km/h)
- Safety: 2 laser area sensors, 2 bumper switches, 2 emergency stops
- Optional aluminium rack (11.7 kg)
- button operating panel
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 160 kg |
|---|---|
| Dimensions | L 1.16 m × W 921 mm × H 249 mm |
| Payload | 500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 3 km/h |
| Environment | Prepared-food and bento factories, including freezers to -25 C and refrigerators |
| Power | |
| Battery Life | 300 min |
| Charging Type | Automatic charging station |
| Sensing & Compute | |
| Sensors | Visual SLAM camera, 2 laser area sensors, bumper switches, magnetic tape sensor |
| Connectivity | Wi-Fi 2.4/5 GHz; Bluetooth remote control; Web UI |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 160 kg |
|---|---|
| Dimensions | L 1.16 m × W 921 mm × H 249 mm |
| Payload | 500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 3 km/h |
| Environment | Prepared-food and bento factories, including freezers to -25 C and refrigerators |
| Power | |
| Battery Life | 300 min |
| Charging Type | Automatic charging station |
| Sensing & Compute | |
| Sensors | Visual SLAM camera, 2 laser area sensors, bumper switches, magnetic tape sensor |
| Connectivity | Wi-Fi 2.4/5 GHz; Bluetooth remote control; Web UI |
Images
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the YL-250F?
The YL-250F is a lift-up autonomous mobile robot for prepared-food and bento factories that carries heavy loads on pallets and racks - up to 500 kg on slopes of up to 3 degrees - into refrigerators and freezers as cold as -25 C without condensation.
Who makes the YL-250F?
The YL-250F is made by GE Creative, a robotics company based in Japan.
How much does the YL-250F cost?
GE Creative has not publicly announced pricing for the YL-250F. You can enquire through RobotAIGeek for current pricing.
What is the YL-250F used for?
The YL-250F is designed for intralogistics, material-handling, and transport. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the YL-250F?
The YL-250F has a payload capacity of 500 kg.
How much does the YL-250F weigh?
The YL-250F weighs 160 kg.
How fast is the YL-250F?
The YL-250F can move at speeds of up to 3 km/h.
What is the battery life of the YL-250F?
The YL-250F runs for about 300 minutes on a charge.
