DESCRIPTION
Shihe Pipe Wire Grinding Robot is a Cleaning-Robots from Shihe Technology. It is built for Cleaning, Grinding, Polishing. Key figures: 50 kg, 30 kg payload, 300 mm reach.
This robot grinds the outside of steel pipe as the preparation step before anti-corrosion coating, and it is built around a licensed abrasive technology: Shihe cites MontiPower's grinding method, which leaves a 40-80 micron surface roughness - the profile a coating needs to key into. It drives on integrated magnetic wheels, so it follows varying curvature, and suits pipe with a curvature radius above 600 mm. A linear motion mechanism extends the grinding reach to 300 mm, and it offers single-ring and multi-ring working modes - one band around the pipe, or repeated passes covering a length. It weighs 50 kg at 650 x 450 x 450 mm, carries up to 30 kg, works at 0-12 m2/h and crosses 5 mm obstacles. A force sensor on the attachment holds constant grinding pressure, and an automatic mode runs the machine back and forth around the pipe unattended while a manual mode lets the operator set range, angle and force by hand.
FEATURES
- MontiPower grinding technology leaving 40-80 micron surface roughness
- Integrated magnetic wheel drive adapting to varying curvature
- Suits steel pipe with curvature radius greater than 600 mm
- Linear motion mechanism extending grinding range to 300 mm
- Single-ring and multi-ring working modes
- Automatic mode runs unattended around the pipe
- manual mode sets range, angle and force
- Force sensor on the attachment for constant-force grinding
- Self weight 50 kg
- dimensions 650 x 450 x 450 mm
- maximum load 30 kg
- Working efficiency 0-12 m2/h
- working width 300 mm
- Minimum adaptable curvature radius 0.3 m
- obstacle crossing height 5 mm
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 50 kg |
|---|---|
| Dimensions | L 650 mm × W 450 mm × H 450 mm |
| Payload | 30 kg |
| Reach | 300 mm |
| Mobility | |
| Movement Type | Wheeled |
| Manipulation | Low |
| Environment | External surfaces of steel pipe with curvature radius above 600 mm, ahead of anti-corrosion coating |
| Actuators | Integrated magnetic wheel drive with a linear motion mechanism extending grinding reach to 300 mm under force control |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 50 kg |
|---|---|
| Dimensions | L 650 mm × W 450 mm × H 450 mm |
| Payload | 30 kg |
| Reach | 300 mm |
| Mobility | |
| Movement Type | Wheeled |
| Manipulation | Low |
| Environment | External surfaces of steel pipe with curvature radius above 600 mm, ahead of anti-corrosion coating |
| Actuators | Integrated magnetic wheel drive with a linear motion mechanism extending grinding reach to 300 mm under force control |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Shihe Pipe Wire Grinding Robot?
This robot grinds the outside of steel pipe as the preparation step before anti-corrosion coating, and it is built around a licensed abrasive technology: Shihe cites MontiPower's grinding method, which leaves a 40-80 micron surface roughness - the profile a coating needs to key into.
Who makes the Shihe Pipe Wire Grinding Robot?
The Shihe Pipe Wire Grinding Robot is made by Shihe Technology, a robotics company based in China.
How much does the Shihe Pipe Wire Grinding Robot cost?
Shihe Technology has not publicly announced pricing for the Shihe Pipe Wire Grinding Robot. You can enquire through RobotAIGeek for current pricing.
What is the Shihe Pipe Wire Grinding Robot used for?
The Shihe Pipe Wire Grinding Robot is designed for cleaning, grinding, and polishing. It is used in energy, construction, and manufacturing settings.
What is the payload capacity of the Shihe Pipe Wire Grinding Robot?
The Shihe Pipe Wire Grinding Robot has a payload capacity of 30 kg and a reach of 300 mm.
How much does the Shihe Pipe Wire Grinding Robot weigh?
The Shihe Pipe Wire Grinding Robot weighs 50 kg.
