DESCRIPTION
OHand™ OYM-011 is an End-Effectors from OYMotion Technologies. It is built for Manipulation, Medical-Assistance, Research.
The OHand OYM-011 is OYMotion's intelligent bionic hand, supplied in standard and small sizes as a prosthetic hand head. The standard hand measures 179 mm from middle fingertip to wrist and 83 mm across the palm; the small version is 157 mm and 76 mm. Wrist rotation covers plus or minus 175 degrees, the thumb abducts through 0-31 degrees at the side and 0-50 degrees in opposition. OYMotion rates a full open-to-close cycle at one second, with active fingertip push force of at least 0.45 kgf at the index finger and at least 1.1 kgf at the thumb, and a two- or three-finger pinch of at least 1.1 kgf. The hand is used for prosthetics and, alongside the company's gForce EMG armbands, in gesture interaction and robotics research.
FEATURES
- Standard and small hand sizes (179 mm and 157 mm fingertip to wrist)
- Wrist rotation of plus/minus 175 degrees
- Thumb side abduction 0-31 degrees, opposition 0-50 degrees
- Full open-to-close cycle in one second
- Index fingertip push force at least 0.45 kgf
- Thumb fingertip push force at least 1.1 kgf
- Two- and three-finger pinch force at least 1.1 kgf
TECHNICAL SPECIFICATIONS
| Mobility | |
| Movement Type | Stationary |
|---|---|
| Manipulation | High |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Mobility | |
| Movement Type | Stationary |
|---|---|
| Manipulation | High |
Images
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the OHand™ OYM-011?
The OHand OYM-011 is OYMotion's intelligent bionic hand, supplied in standard and small sizes as a prosthetic hand head. The standard hand measures 179 mm from middle fingertip to wrist and 83 mm across the palm; the small version is 157 mm and 76 mm.
Who makes the OHand™ OYM-011?
The OHand™ OYM-011 is made by OYMotion Technologies, a robotics company based in China.
How much does the OHand™ OYM-011 cost?
OYMotion Technologies has not publicly announced pricing for the OHand™ OYM-011. You can enquire through RobotAIGeek for current pricing.
What is the OHand™ OYM-011 used for?
The OHand™ OYM-011 is designed for manipulation, medical-assistance, and research. It is used in consumer, research, and healthcare settings.
