Galileo S1

Galileo Technology

Industrial-Robot China

ChinaReleased

★Not rated yet

Compare

Sources:

galileotime.com

Industries:

Energy Research Manufacturing Security & Patrol

Uses:

Inspection Monitoring TransportIndustrial inspection in toxic, hazardous and high-risk workplacessecurity patrolmaterial transportdemolition and emergency support with mounted toolingresearch platforms

Price:

Not announced

DESCRIPTION

Galileo S1 is an Industrial-Robot from Galileo Technology. It is built for Inspection, Monitoring, Transport. Key figures: 118 kg, 210 min runtime, 100 kg payload.

The Galileo S1 is the large industrial grade and the heavy carrier of the family: 118 kg of machine rated to a 100 kg working payload and a 170 kg maximum, which is close to carrying its own weight again. Power comes from a dual-battery arrangement running at 59 V rather than the 48 V of the smaller grades, totalling 60 Ah and 3,540 Wh — more than double the E1's energy — and that buys the longest loaded endurance in the range at three and a half hours under payload and five unloaded. It is deliberately not the fastest, topping out at 3.5 m/s, because at this mass the design priority is stable load-bearing rather than pace. Twin LiDARs and dual ARM-plus-X86 compute are standard, and its external interfaces add a 12 V supply and USB 3.0 over the medium grade.

FEATURES

Largest legged model: 100 kg rated payload, 170 kg maximum load, and a dual-battery 3,540 Wh pack
1200 x 550 x 650 mm standing at 118 kg
Motion speed adjustable from 0 to 3.5 m/s
100 kg rated payload capacity with a 170 kg maximum load
Maximum climbable slope of 30 degrees or more
continuous steps of 30 cm or more
front-facing 80 cm elevation platform
60 Ah (3540 Wh), dual battery at 59 V battery giving 3.5 hours under payload and 5 hours unloaded, with a range of >12 km
LiDAR: 2 units, one front and one rear, 30 m detection range, 0-360 degrees horizontal and 0-90 degrees vertical
Domestic ARM-based low-power high-performance CPU with 8 cores and 8 threads, 8 GB RAM and 64 GB solid-state storage
WiFi 6 wireless networking with optional 4G and 5G
communication bandwidth of 6 Mbps or less
1920 x 1080 camera at 25 fps, 2 megapixels
IP67 protection
Operating temperature from -20 to 55 degrees Celsius
Removable battery supporting automatic charging at up to 960 W
Charger input 100-240 V
Optional voice interaction
supplied with a remote-control handle
Customisable payloads including dual-spectrum gimbals, 4G/5G and BeiDou/GPS/RTK modules, robotic arms, compact radar, cargo carriers, demolition tools and explosion-proof equipment
Low-power standby mode of 365 days or more with remote wake-up support
Lithium battery with autonomous charging supported
Secondary development supported

TECHNICAL SPECIFICATIONS

Verified

Physical
Weight	118 kg
Dimensions	L 1.2 m × W 550 mm × H 650 mm
Payload	100 kg
Mobility
Movement Type	Quadruped
Speed	12.6 km/h
Environment	All-weather industrial and outdoor use; IP67; -20 to 55 degrees Celsius, -20°C to 55°C
Actuators	Bionic quadruped with articulated legs
Power
Battery Life	3.5-5 h
Sensing & Compute
Sensors	LiDAR, 1920x1080 camera at 25 fps
Connectivity	WiFi 6, optional 4G and 5G; Ethernet, USB and RS485 external interfaces
Software / AI	Autonomous navigation and obstacle avoidance with multi-sensor fusion

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Verified

Physical
Weight	118 kg
Dimensions	L 1.2 m × W 550 mm × H 650 mm
Payload	100 kg
Mobility
Movement Type	Quadruped
Speed	12.6 km/h
Environment	All-weather industrial and outdoor use; IP67; -20 to 55 degrees Celsius, -20°C to 55°C
Actuators	Bionic quadruped with articulated legs
Power
Battery Life	3.5-5 h
Sensing & Compute
Sensors	LiDAR, 1920x1080 camera at 25 fps
Connectivity	WiFi 6, optional 4G and 5G; Ethernet, USB and RS485 external interfaces
Software / AI	Autonomous navigation and obstacle avoidance with multi-sensor fusion

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Galileo S1?

Who makes the Galileo S1?

The Galileo S1 is made by Galileo Technology, a robotics company based in China.

How much does the Galileo S1 cost?

Galileo Technology has not publicly announced pricing for the Galileo S1. You can enquire through RobotAIGeek for current pricing.

What is the Galileo S1 used for?

The Galileo S1 is designed for inspection, monitoring, transport, and industrial inspection in toxic, hazardous and high-risk workplaces. It is used in energy, research, manufacturing, and security & patrol settings.
