DESCRIPTION
The 12 t AGV is a Backpack Heavy-duty AGV built by Lonyu AGV, rated to carry 12 t (the figure Lonyu gives in the product name; the page carries no separate rated-load row). It has a body measuring 3400 mm long, 1200 mm wide and 440 mm high and an unladen mass of 3 t. Lonyu describes its movement as: Straight forward and backward, left and right, rotation in place. It navigates by magnetic strip. For power and motion, charging is manual charging or automatic charging (when the AGV automatically detects that it is lower than the set value, it will automatically run to the charging device for automatic charging), automatic charging includes contact; travel speed is The speed of indoor AGV is 0-60m/min. If the speed is higher, it depends on the actual situation. However, considering the on-site environment of general production enterprises, the safety of personnel, and the weight of. On safety, safety is handled by laser obstacle avoidance sensor + safety edge touch + sound and light alarm + emergency stop button. Lonyu rates it for indoor.
FEATURES
- Rated load: 12 t (per Lonyu's model name)
- Unladen mass: 3 t
- Body dimensions: 3400 x 1200 x 440 mm
- Drive type: Differential
- Navigation: Magnetic strip
- Travel speed: The speed of indoor AGV is 0-60m/min. If the speed is higher, it depends on the actual situation. However, considering the on-site environment of gene
- Charging: manual charging or automatic charging (when the AGV automatically detects that it is lower than the set value, it will automatically run to the chargi
- Safety systems: Laser obstacle avoidance sensor + safety edge touch + sound and light alarm + emergency stop button
- Operating environment: Indoor
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 3000 kg |
|---|---|
| Dimensions | L 3.4 m × W 1.2 m × H 440 mm |
| Payload | 12000 kg |
| Mobility | |
| Speed | 3.6 km/h |
| Environment | Indoor |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 3000 kg |
|---|---|
| Dimensions | L 3.4 m × W 1.2 m × H 440 mm |
| Payload | 12000 kg |
| Mobility | |
| Speed | 3.6 km/h |
| Environment | Indoor |
Images
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the 12 t AGV?
The 12 t AGV is a Backpack Heavy-duty AGV built by Lonyu AGV, rated to carry 12 t (the figure Lonyu gives in the product name; the page carries no separate rated-load row). It has a body measuring 3400 mm long, 1200 mm wide and 440 mm high and an unladen mass of 3 t.
Who makes the 12 t AGV?
The 12 t AGV is made by Lonyu Agv.
How much does the 12 t AGV cost?
Lonyu Agv has not publicly announced pricing for the 12 t AGV. You can enquire through RobotAIGeek for current pricing.
What is the 12 t AGV used for?
The 12 t AGV is designed for transport.
What is the payload capacity of the 12 t AGV?
The 12 t AGV has a payload capacity of 12,000 kg.
How much does the 12 t AGV weigh?
The 12 t AGV weighs 3,000 kg.
How fast is the 12 t AGV?
The 12 t AGV can move at speeds of up to 3.6 km/h.
