DESCRIPTION
Zamma TS Counterbalance C12 is an Industrial-Robot from DF Automation. It is built for Lifting, Material-Handling, Pallet-Transportation. Key figures: 1885 kg, 300 min runtime, 1200 kg payload.
Zamma TS Counterbalance C12 (ZAMMA-SL-TS-C12) is DF Automation & Robotics' autonomous counterbalance forklift, which lifts pallets of up to 1.2 tonnes to about 3 m. It measures 2,626 x 1,000 x 2,200 mm and weighs 1,885 kg including its battery, navigates by laser natural feature navigation with marker support, and travels at up to 1.6 m/s. A 24 V, 345 Ah lithium-ion battery runs it for about 5 hours with automatic dock charging, and it is programmed through NavWiz and managed with DFleet, with safety laser scanners and emergency stops.
FEATURES
- Lifting payload 1,200 kg
- lift height about 3 m
- counterbalance design
- 2,626 x 1,000 x 2,200 mm
- 1,885 kg incl. battery
- Laser natural-feature navigation with marker support
- Speed up to 1.6 m/s
- Li-ion 24 V 345 Ah
- ~5 h running time
- auto dock charging
- Safety laser scanners and emergency stops
- NavWiz mapping and flowchart task programming
- DFleet fleet management
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 1885 kg |
|---|---|
| Dimensions | L 2.63 m × W 1 m × H 2.2 m |
| Payload | 1200 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Warehouses and production logistics (indoor) |
| Power | |
| Battery Life | 300 min |
| Sensing & Compute | |
| Sensors | safety laser scanners |
| Connectivity | Dual-band Wi-Fi |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 1885 kg |
|---|---|
| Dimensions | L 2.63 m × W 1 m × H 2.2 m |
| Payload | 1200 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Warehouses and production logistics (indoor) |
| Power | |
| Battery Life | 300 min |
| Sensing & Compute | |
| Sensors | safety laser scanners |
| Connectivity | Dual-band Wi-Fi |
Images
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Zamma TS Counterbalance C12?
Zamma TS Counterbalance C12 (ZAMMA-SL-TS-C12) is DF Automation & Robotics' autonomous counterbalance forklift, which lifts pallets of up to 1.2 tonnes to about 3 m.
Who makes the Zamma TS Counterbalance C12?
The Zamma TS Counterbalance C12 is made by DF Automation, a robotics company based in Malaysia.
How much does the Zamma TS Counterbalance C12 cost?
DF Automation has not publicly announced pricing for the Zamma TS Counterbalance C12. You can enquire through RobotAIGeek for current pricing.
What is the Zamma TS Counterbalance C12 used for?
The Zamma TS Counterbalance C12 is designed for lifting, material-handling, and pallet-transportation. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the Zamma TS Counterbalance C12?
The Zamma TS Counterbalance C12 has a payload capacity of 1,200 kg.
How much does the Zamma TS Counterbalance C12 weigh?
The Zamma TS Counterbalance C12 weighs 1,885 kg.
How fast is the Zamma TS Counterbalance C12?
The Zamma TS Counterbalance C12 can move at speeds of up to 5.76 km/h.
What is the battery life of the Zamma TS Counterbalance C12?
The Zamma TS Counterbalance C12 runs for about 300 minutes on a charge.
