DESCRIPTION
U1500OXN is an Industrial-Robot from Asseco CEIT. It is built for Intralogistics, Lifting, Material-Handling. Key figures: 1500 kg payload.
U1500OXN is Asseco CEIT's omnidirectional under-run AGV: it moves in any direction and rotates on the spot, carries 1,500 kg, lifts by 130 mm in its lifting versions and travels at up to 1.6 m/s, which makes it suited to tight production spaces. It navigates by contour, has two 270-degree SICK safety scanners for 360-degree protection (optional 2D scanner and 3D camera) and charges automatically, wirelessly or by contact. Variants are U1500OXN, ORN, OXW and ORW (narrow/wide, fixed/lifting); the wide versions are 912 mm wide.
FEATURES
- Load capacity 1,500 kg
- lifting versions 130 mm stroke
- Omnidirectional drive, on-the-spot rotation
- min. turning radius 0.8 m
- Max. speed 1.6 m/s
- Contour navigation
- SICK 2 x 270 deg safety scanners
- optional 2D scanner and 3D camera
- Automatic wireless or contact charging
- 1,487 x 752 x 305 mm (wide versions 912 mm wide)
- variants OXN/ORN/OXW/ORW
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.49 m × W 752 mm × H 305 mm |
|---|---|
| Payload | 1500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Factories and warehouses (indoor) |
| Power | |
| Charging Type | Automatic - wireless or contact |
| Sensing & Compute | |
| Sensors | SICK safety laser scanners (2 x 270 deg), optional 3D camera |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.49 m × W 752 mm × H 305 mm |
|---|---|
| Payload | 1500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Factories and warehouses (indoor) |
| Power | |
| Charging Type | Automatic - wireless or contact |
| Sensing & Compute | |
| Sensors | SICK safety laser scanners (2 x 270 deg), optional 3D camera |
Images
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the U1500OXN?
U1500OXN is Asseco CEIT's omnidirectional under-run AGV: it moves in any direction and rotates on the spot, carries 1,500 kg, lifts by 130 mm in its lifting versions and travels at up to 1.6 m/s, which makes it suited to tight production spaces.
Who makes the U1500OXN?
The U1500OXN is made by Asseco CEIT, a robotics company based in Slovak Republic.
How much does the U1500OXN cost?
Asseco CEIT has not publicly announced pricing for the U1500OXN. You can enquire through RobotAIGeek for current pricing.
What is the U1500OXN used for?
The U1500OXN is designed for intralogistics, lifting, material-handling, and transport. It is used in automotive, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the U1500OXN?
The U1500OXN has a payload capacity of 1,500 kg.
How fast is the U1500OXN?
The U1500OXN can move at speeds of up to 5.76 km/h.
