DESCRIPTION
Tomas-T is an Industrial-Robot from Yeefung. It is built for Intralogistics, Material-Handling, Transport. Key figures: 300 kg.
Tomas-T is Yeefung's trailer-type tugger AGV. It navigates naturally by comparing its stored path with the real-time profile of the building, so no floor markers are needed, and tows up to 1 t. Yeefung pitches it as a more flexible, cheaper-to-install alternative to conveyors. It measures 1000 x 650 x 800 mm, weighs 300 kg, travels at up to 1.5 m/s, and positions to +/-5mm. Power comes from a 48V Lithium 38Ah battery with automatic or manual charging; it communicates over WLAN, and E-stops, non-contact and mechanical protection plus a SICK S300 laser obstacle scanner keep it safe.
FEATURES
- Navigation accuracy +/-10mm
- positioning accuracy +/-5mm
- Navigation: Visual/Natural navigation
- Moving function: Forward, backward, turning
- Drive mode: Single steering drive
- Size: 1000mm(L) x 650mm(W) x 800mm(H)
- Working mode: Trail & Traction
- MAX Payload: 1000kg
- Weight: 300kg
- Driving speed(MAX): 1.5m/s
- Turning speed(MAX): 0.5m/s
- Turning radius(MIN): 940mm
- Battery: 48V Lithium 38Ah
- Charger power: 3.5KW
- Distance between AGV chassis and ground: 30mm
- Gradeability: 3%
- Laser obstacle avoidance device: SICK S300
- Safety: E-stop, Non-Contact protection, mechanical protection
- sensing range 0-3m
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 300 kg |
|---|---|
| Dimensions | L 1 m × W 650 mm × H 800 mm |
| Repeatability | ±5 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Actuators | Single steering drive |
| Power | |
| Battery Life | 48V Lithium 38Ah |
| Charging Type | Automatic / manual charging |
| Sensing & Compute | |
| Sensors | Visual/Natural navigation sensors, SICK S300 laser obstacle scanner |
| Connectivity | WLAN |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 300 kg |
|---|---|
| Dimensions | L 1 m × W 650 mm × H 800 mm |
| Repeatability | ±5 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Actuators | Single steering drive |
| Power | |
| Battery Life | 48V Lithium 38Ah |
| Charging Type | Automatic / manual charging |
| Sensing & Compute | |
| Sensors | Visual/Natural navigation sensors, SICK S300 laser obstacle scanner |
| Connectivity | WLAN |
Images
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Tomas-T?
Tomas-T is Yeefung's trailer-type tugger AGV. It navigates naturally by comparing its stored path with the real-time profile of the building, so no floor markers are needed, and tows up to 1 t. Yeefung pitches it as a more flexible, cheaper-to-install alternative to conveyors.
Who makes the Tomas-T?
The Tomas-T is made by Yeefung, a robotics company based in China.
How much does the Tomas-T cost?
Yeefung has not publicly announced pricing for the Tomas-T. You can enquire through RobotAIGeek for current pricing.
What is the Tomas-T used for?
The Tomas-T is designed for intralogistics, material-handling, transport, and automated material handling. It is used in automotive, warehouse & logistics, and manufacturing settings.
How much does the Tomas-T weigh?
The Tomas-T weighs 300 kg.
How fast is the Tomas-T?
The Tomas-T can move at speeds of up to 5.4 km/h.
