Peitian AIR4-560A

Peitian Robot

Industrial-Robot China

ChinaReleased

★Not rated yet

Compare

Sources:

cdn.robotaigeek.com

Industries:

Research Manufacturing

Uses:

Assembly Pick-and-placeLoading and unloadinghandlingpalletisinginjection mouldingweldinggrinding and polishingdispensingpacking

Price:

Not announced

DESCRIPTION

Peitian AIR4-560A is an Industrial-Robot from Peitian Robot. It is built for Assembly, Pick-and-place, Loading and unloading. Key figures: 23 kg, 4 kg payload, 560 mm reach, 6 degrees of freedom.

The AIR4-560A is a desktop-class six-axis articulated arm from Peitian's AIR range, carrying 4 kg to a reach of 560 mm. Peitian quotes position repeatability of ±0.02mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 23 kg. It is sealed to IP65, and can be mounted Floor or wall or ceiling. It runs on Peitian's inCube20 / ARC5-12 controller cabinet.

FEATURES

Six-axis articulated industrial robot arm
Rated payload 4 kg
Maximum reach 560 mm
Manipulator weight 23 kg
Position repeatability ±0.02mm
Ingress protection IP65
Mounting: Floor / wall / ceiling
Compatible controller cabinets: inCube20 / ARC5-12
Working range Axis 1 rotation -170°/+170°
Axis 2 arm -110°/+120°
Axis 3 arm -108°/+152°
Axis 4 wrist -200°/+200°
Axis 5 bend -118°/+118°
Axis 6 turn -350°/+350°
Rotation rate Axis 1 rotation 450°/s
Axis 2 arm 450°/s
Axis 3 arm 525°/s
Axis 4 wrist 600°/s
Axis 5 bend 600°/s
Axis 6 turn 800°/s
Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
No corrosive, flammable or explosive gases permitted in the operating environment

TECHNICAL SPECIFICATIONS

Physical
Weight	23 kg
Payload	4 kg
Reach	560 mm
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube20 / ARC5-12 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Physical
Weight	23 kg
Payload	4 kg
Reach	560 mm
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube20 / ARC5-12 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Peitian AIR4-560A?

Who makes the Peitian AIR4-560A?

The Peitian AIR4-560A is made by Peitian Robot, a robotics company based in China.

How much does the Peitian AIR4-560A cost?

Peitian Robot has not publicly announced pricing for the Peitian AIR4-560A. You can enquire through RobotAIGeek for current pricing.

What is the Peitian AIR4-560A used for?

The Peitian AIR4-560A is designed for assembly, pick-and-place, loading and unloading, and handling. It is used in research and manufacturing settings.
