BESCHREIBUNG
The AIR4-560A is a desktop-class six-axis articulated arm from Peitian's AIR range, carrying 4 kg to a reach of 560 mm. Peitian quotes position repeatability of ±0.02mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 23 kg. It is sealed to IP65, and can be mounted Floor or wall or ceiling. It runs on Peitian's inCube20 / ARC5-12 controller cabinet.
FUNKTIONEN
- Six-axis articulated industrial robot arm
- Rated payload 4 kg
- Maximum reach 560 mm
- Manipulator weight 23 kg
- Position repeatability ±0.02mm
- Ingress protection IP65
- Mounting: Floor / wall / ceiling
- Compatible controller cabinets: inCube20 / ARC5-12
- Working range Axis 1 rotation -170°/+170°
- Axis 2 arm -110°/+120°
- Axis 3 arm -108°/+152°
- Axis 4 wrist -200°/+200°
- Axis 5 bend -118°/+118°
- Axis 6 turn -350°/+350°
- Rotation rate Axis 1 rotation 450°/s
- Axis 2 arm 450°/s
- Axis 3 arm 525°/s
- Axis 4 wrist 600°/s
- Axis 5 bend 600°/s
- Axis 6 turn 800°/s
- Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
- No corrosive, flammable or explosive gases permitted in the operating environment
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 23 kg |
|---|---|
| Traglast | 4 kg |
| Reichweite | 560 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
| Einsatzumgebung | Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases |
| Aktoren | 6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling |
| Sensorik & Rechenleistung | |
| Software / KI | Driven by Peitian inCube20 / ARC5-12 controller cabinets |
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 23 kg |
|---|---|
| Traglast | 4 kg |
| Reichweite | 560 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
| Einsatzumgebung | Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases |
| Aktoren | 6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling |
| Sensorik & Rechenleistung | |
| Software / KI | Driven by Peitian inCube20 / ARC5-12 controller cabinets |
Bilder
martti
marttiBildbeiträge
Videos
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the Peitian AIR4-560A?
The AIR4-560A is a desktop-class six-axis articulated arm from Peitian's AIR range, carrying 4 kg to a reach of 560 mm. Peitian quotes position repeatability of ±0.02mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling.
Who makes the Peitian AIR4-560A?
The Peitian AIR4-560A is made by Peitian Robot, a robotics company based in China.
How much does the Peitian AIR4-560A cost?
Peitian Robot has not publicly announced pricing for the Peitian AIR4-560A. You can enquire through RobotAIGeek for current pricing.
What is the Peitian AIR4-560A used for?
The Peitian AIR4-560A is designed for montage, pick-and-place, loading and unloading, and handling. It is used in forschung and fertigung settings.
What is the payload capacity of the Peitian AIR4-560A?
The Peitian AIR4-560A has a payload capacity of 4 kg and a reach of 560 mm.
How much does the Peitian AIR4-560A weigh?
The Peitian AIR4-560A weighs 23 kg.
How many degrees of freedom does the Peitian AIR4-560A have?
The Peitian AIR4-560A has 6 degrees of freedom.
