BESCHREIBUNG
The AIR8-710 is a small-payload six-axis articulated arm from Peitian's AIR range, carrying 8 kg to a reach of 710 mm. Peitian quotes position repeatability of ±0.02mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 49 kg. It is sealed to IP67, and can be mounted Floor or wall or ceiling. It runs on Peitian's inCube20 / ARC5-12 controller cabinet.
FUNKTIONEN
- Six-axis articulated industrial robot arm
- Rated payload 8 kg
- Maximum reach 710 mm
- Manipulator weight 49 kg
- Position repeatability ±0.02mm
- Ingress protection IP67
- Mounting: Floor / wall / ceiling
- Compatible controller cabinets: inCube20 / ARC5-12
- Working range Axis 1 rotation -170°/+170°
- Axis 2 arm -100°/+135°
- Axis 3 arm -120°/+156°
- Axis 4 wrist -200°/+200°
- Axis 5 bend -135°/+135°
- Axis 6 turn -360°/+360°
- Rotation rate Axis 1 rotation 380°/s
- Axis 2 arm 350°/s
- Axis 3 arm 480°/s
- Axis 4 wrist 490°/s
- Axis 5 bend 565°/s
- Axis 6 turn 815°/s
- Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
- No corrosive, flammable or explosive gases permitted in the operating environment
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 49 kg |
|---|---|
| Traglast | 8 kg |
| Reichweite | 710 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
| Einsatzumgebung | Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases |
| Aktoren | 6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling |
| Sensorik & Rechenleistung | |
| Software / KI | Driven by Peitian inCube20 / ARC5-12 controller cabinets |
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 49 kg |
|---|---|
| Traglast | 8 kg |
| Reichweite | 710 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
| Einsatzumgebung | Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases |
| Aktoren | 6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling |
| Sensorik & Rechenleistung | |
| Software / KI | Driven by Peitian inCube20 / ARC5-12 controller cabinets |
Bilder
martti
marttiBildbeiträge
Videos
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the Peitian AIR8-710?
The AIR8-710 is a small-payload six-axis articulated arm from Peitian's AIR range, carrying 8 kg to a reach of 710 mm. Peitian quotes position repeatability of ±0.02mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling.
Who makes the Peitian AIR8-710?
The Peitian AIR8-710 is made by Peitian Robot, a robotics company based in China.
How much does the Peitian AIR8-710 cost?
Peitian Robot has not publicly announced pricing for the Peitian AIR8-710. You can enquire through RobotAIGeek for current pricing.
What is the Peitian AIR8-710 used for?
The Peitian AIR8-710 is designed for montage, pick-and-place, loading and unloading, and handling. It is used in forschung and fertigung settings.
What is the payload capacity of the Peitian AIR8-710?
The Peitian AIR8-710 has a payload capacity of 8 kg and a reach of 710 mm.
How much does the Peitian AIR8-710 weigh?
The Peitian AIR8-710 weighs 49 kg.
How many degrees of freedom does the Peitian AIR8-710 have?
The Peitian AIR8-710 has 6 degrees of freedom.
