DESCRIPTION
Lanxin VB2 is a Consumer-Robot from Lanxin Robotics. It is built for Research, Helping. Key figures: 5 kg payload.
VB2 is the larger of Lanxin's two humanoid service robots, and the step up from the VB1 is in the arms and the reach rather than the footprint. It has seven arm joints against the VB1's six, grips 5 kg against 2, and works across a height range of 0.4 to 2 m, which covers everything from a low shelf to an overhead one. Battery life roughly doubles too, at four to six hours. It stands 1,700 mm on a 580 by 480 mm base with a 760 mm rotation diameter, so it turns inside its own footprint in a corridor, and rides 35 mm off the ground. Travel is up to 1.2 m/s. Navigation is 3D laser SLAM, which is the company's own speciality — Lanxin builds the 3D vision sensors these robots run on.
FEATURES
- Operating height range 0.4 to 2 m
- Seven arm joints
- Gripping load 5 kg
- Battery life 4 to 6 hours
- Dimensions 580 x 480 x 1700 mm
- Rotation diameter 760 mm
- Ground clearance 35 mm
- Travel speed 0 to 1.2 m/s
- 3D laser SLAM navigation
- Working temperature 0 to 40 degrees C
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 580 mm × W 480 mm × H 1.7 m |
|---|---|
| Payload | 5 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 4.32 km/h |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 580 mm × W 480 mm × H 1.7 m |
|---|---|
| Payload | 5 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 4.32 km/h |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Lanxin VB2?
VB2 is the larger of Lanxin's two humanoid service robots, and the step up from the VB1 is in the arms and the reach rather than the footprint.
Who makes the Lanxin VB2?
The Lanxin VB2 is made by Lanxin Robotics, a robotics company based in China.
How much does the Lanxin VB2 cost?
Lanxin Robotics has not publicly announced pricing for the Lanxin VB2. You can enquire through RobotAIGeek for current pricing.
What is the Lanxin VB2 used for?
The Lanxin VB2 is designed for research and helping. It is used in research and homes settings.
What is the payload capacity of the Lanxin VB2?
The Lanxin VB2 has a payload capacity of 5 kg.
How fast is the Lanxin VB2?
The Lanxin VB2 can move at speeds of up to 4.32 km/h.
