DESCRIPTION
The L1200S is the low-profile member of the family: 330 mm tall, so it drives underneath a goods carrier, lifts it and takes it away. That shape is why it suits plants where trolleys and racks, rather than pallets, are the unit of movement. It carries about 1,200 kg at up to 2 m/s, positions to roughly plus or minus 15 mm, and navigates by free contour navigation with two certified safety laser scanners — no tape or reflectors on the floor. The footprint is 1,263 by 695 mm. Options include autonomous load-carrier detection, drive-range monitoring, a blue warning light and a brush strip.
FEATURES
- Under-ride AGV that drives beneath a goods carrier, lifts and transports it
- Payload approx. 1,200 kg
- Dimensions 1,263 x 695 x 330 mm (L/W/H) — 330 mm tall for under-ride work
- Speed up to 2 m/s
- Positioning accuracy approx. +/-15 mm typical
- Two certified safety laser scanners
- Free contour navigation
- Options: autonomous load-carrier detection, drive-range monitoring, blue light, brush strip
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.26 m × W 695 mm × H 330 mm |
|---|---|
| Payload | 1200 kg |
| Repeatability | ±15 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 2 km/h |
| Environment | Indoor factory and warehouse floors in shared traffic; no floor infrastructure required |
| Sensing & Compute | |
| Sensors | two certified safety laser scanners, contour-navigation sensing |
| Software / AI | Grenzebach fleet manager Warehouse control system Security manager and statistics |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.26 m × W 695 mm × H 330 mm |
|---|---|
| Payload | 1200 kg |
| Repeatability | ±15 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 2 km/h |
| Environment | Indoor factory and warehouse floors in shared traffic; no floor infrastructure required |
| Sensing & Compute | |
| Sensors | two certified safety laser scanners, contour-navigation sensing |
| Software / AI | Grenzebach fleet manager Warehouse control system Security manager and statistics |
Images
martti
marttiImage Contributions
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Grenzebach L1200S?
The L1200S is the low-profile member of the family: 330 mm tall, so it drives underneath a goods carrier, lifts it and takes it away. That shape is why it suits plants where trolleys and racks, rather than pallets, are the unit of movement.
Who makes the Grenzebach L1200S?
The Grenzebach L1200S is made by Grenzebach, a robotics company based in Germany.
How much does the Grenzebach L1200S cost?
Grenzebach has not publicly announced pricing for the Grenzebach L1200S. You can enquire through RobotAIGeek for current pricing.
What is the Grenzebach L1200S used for?
The Grenzebach L1200S is designed for intralogistics, material-handling, and transport. It is used in automotive, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the Grenzebach L1200S?
The Grenzebach L1200S has a payload capacity of 1,200 kg.
How fast is the Grenzebach L1200S?
The Grenzebach L1200S can move at speeds of up to 2 km/h.
