DESCRIPTION
G451 is an Industrial-Robot from Sevnce Robotics. It is built for Inspection, Patrol, Explosion-proof inspection and emergency robotics. Key figures: 230 kg.
The G451 is Sevnce's explosion-proof rail-hung inspection robot (Ex IIB T4 Gb, IP66) running on parallel twin rails, which keep it stable and precise and resist disturbances. It is built for long, continuous patrols covering equipment areas around the clock, with up to 40 km per charge. Twin-rail two-wheel drive moves it at up to 1 m/s with braking within 0.1 m on the level (0.3 m on grades) and a 3 m turning diameter; it climbs 5-degree grades, positions to +/-1 cm by odometry, Hall sensors and RFID, recharges in up to four hours and works between -20 and 60 C. It measures up to 880 x 600 x 700 mm and 230 kg. Standard functions include autonomous inspection, obstacle avoidance, remote control, video monitoring, offline inspection, sound-and-light alarm, auxiliary lighting, autonomous charging, two-way voice and one-key return.
FEATURES
- Explosion protection Ex IIB T4 Gb
- IP66
- Parallel twin-rail design
- twin-rail two-wheel drive
- Range up to 40 km per charge
- charging up to 4 h
- Up to 880 x 600 x 700 mm
- up to 230 kg
- Speed up to 1 m/s
- braking 0.1 m level / 0.3 m grade
- turning diameter 300 cm
- Grades up to 5 deg
- Positioning: odometry + Hall sensors + RFID, +/-1 cm
- Operating temperature -20 to 60 C
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 230 kg |
|---|---|
| Dimensions | L 880 mm × W 600 mm × H 700 mm |
| Mobility | |
| Movement Type | Other |
| Speed | 3.6 km/h |
| Environment | Plant equipment areas, pipe racks and galleries on parallel twin rails |
| Sensing & Compute | |
| Sensors | odometer, Hall sensors, RFID reader, cameras |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 230 kg |
|---|---|
| Dimensions | L 880 mm × W 600 mm × H 700 mm |
| Mobility | |
| Movement Type | Other |
| Speed | 3.6 km/h |
| Environment | Plant equipment areas, pipe racks and galleries on parallel twin rails |
| Sensing & Compute | |
| Sensors | odometer, Hall sensors, RFID reader, cameras |
Images
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the G451?
The G451 is Sevnce's explosion-proof rail-hung inspection robot (Ex IIB T4 Gb, IP66) running on parallel twin rails, which keep it stable and precise and resist disturbances. It is built for long, continuous patrols covering equipment areas around the clock, with up to 40 km per charge.
Who makes the G451?
The G451 is made by Sevnce Robotics, a robotics company based in China.
How much does the G451 cost?
Sevnce Robotics has not publicly announced pricing for the G451. You can enquire through RobotAIGeek for current pricing.
What is the G451 used for?
The G451 is designed for inspection, patrol, and explosion-proof inspection and emergency robotics. It is used in energy and manufacturing settings.
How much does the G451 weigh?
The G451 weighs 230 kg.
How fast is the G451?
The G451 can move at speeds of up to 3.6 km/h.
