DESCRIPTION
D071 is an Industrial-Robot from Sevnce Robotics. It is built for Inspection, Patrol, Explosion-proof inspection and emergency robotics. Key figures: 550 kg, 180 min runtime.
The D071 is Sevnce's explosion-proof tracked inspection robot (Ex IIB T4 Gb, IP66). Its track system copes with harder ground than wheels, and the large footprint and special tread pattern suit extreme cold, rain and snow, slippery surfaces and mountainous terrain; modular, independent sensing and control units keep it running reliably. Twin-track drive moves it at up to 1.4 m/s with a 2.42 m turning diameter; it climbs 30-degree slopes and 15 cm obstacles, wades 12 cm, navigates by laser to +/-5 cm and runs up to three hours with up to five-hour charging between -25 and 60 C. It measures up to 1,420 x 900 x 1,120 mm and 550 kg. Standard functions include autonomous inspection, obstacle avoidance, remote control, video monitoring, offline inspection, sound-and-light alarm, auxiliary lighting, autonomous charging, two-way voice and one-key return, with options for laser telemetry, acoustic imaging, voiceprint and noise detection and BeiDou navigation.
FEATURES
- Explosion protection Ex IIB T4 Gb
- IP66
- Twin-track drive for snow, slippery and mountainous ground
- Up to 1,420 x 900 x 1,120 mm
- up to 550 kg
- Speed up to 1.4 m/s
- turning diameter 242 cm
- Slopes up to 30 deg
- obstacles up to 15 cm
- wading 12 cm
- Laser navigation
- accuracy +/-5 cm
- Runtime up to 3 h
- charging up to 5 h
- Operating temperature -25 to 60 C
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 550 kg |
|---|---|
| Dimensions | L 1.42 m × W 900 mm × H 1.12 m |
| Mobility | |
| Movement Type | Other |
| Speed | 5.04 km/h |
| Environment | Explosive and hazardous industrial sites (oil, chemical, gas, power), indoor and outdoor; extreme cold, rain, snow, slippery and mountainous ground |
| Power | |
| Battery Life | 180 min |
| Sensing & Compute | |
| Sensors | 2D LiDAR (laser navigation), cameras |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 550 kg |
|---|---|
| Dimensions | L 1.42 m × W 900 mm × H 1.12 m |
| Mobility | |
| Movement Type | Other |
| Speed | 5.04 km/h |
| Environment | Explosive and hazardous industrial sites (oil, chemical, gas, power), indoor and outdoor; extreme cold, rain, snow, slippery and mountainous ground |
| Power | |
| Battery Life | 180 min |
| Sensing & Compute | |
| Sensors | 2D LiDAR (laser navigation), cameras |
Images
martti
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the D071?
The D071 is Sevnce's explosion-proof tracked inspection robot (Ex IIB T4 Gb, IP66). Its track system copes with harder ground than wheels, and the large footprint and special tread pattern suit extreme cold, rain and snow, slippery surfaces and mountainous terrain; modular, independent sensing and control units keep it…
Who makes the D071?
The D071 is made by Sevnce Robotics, a robotics company based in China.
How much does the D071 cost?
Sevnce Robotics has not publicly announced pricing for the D071. You can enquire through RobotAIGeek for current pricing.
What is the D071 used for?
The D071 is designed for inspection, patrol, and explosion-proof inspection and emergency robotics. It is used in energy and manufacturing settings.
How much does the D071 weigh?
The D071 weighs 550 kg.
How fast is the D071?
The D071 can move at speeds of up to 5.04 km/h.
What is the battery life of the D071?
The D071 runs for about 180 minutes on a charge.
