DESCRIPTION
Esachain P is a Mobile-Robots from Esatroll. It is built for Material-Handling, Transport, Laser-guided AGV that carries a full pallet above and an empty pallet below on motorised chains. Key figures: 1000 kg payload.
Esachain P is a laser-guided turtle vehicle with motorised chains on two levels: it carries a full pallet of up to 1,000 kg on top and an empty pallet on the lower level. It uses ANT laser navigation, which takes any fixed element of the surroundings as a reference so installation is quick, receives missions over Wi-Fi from Esatroll's supervisor or the plant's own system, and can be fitted with opportunity charging. Like Esatroll's other vehicles it is designed and built in-house in Switzerland and adapted to each customer's plant, and it can be run by Esatroll's customised supervisor, which takes calls from workstations, assigns vehicles, manages right of way and load delivery and logs activity.
FEATURES
- Motorised chains on two levels: full pallet + empty pallet
- Up to 1,000 kg
- ANT laser navigation
- no reflectors needed
- Front and rear laser scanners, bumpers
- Up to 1.2 m/s
- 48 V
- opportunity charging
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Payload | 1000 kg |
|---|---|
| Mobility | |
| Movement Type | Wheeled |
| Speed | 4.32 km/h |
| Environment | Indoor factories and warehouses |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Payload | 1000 kg |
|---|---|
| Mobility | |
| Movement Type | Wheeled |
| Speed | 4.32 km/h |
| Environment | Indoor factories and warehouses |
Images
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Esachain P?
Esachain P is a laser-guided turtle vehicle with motorised chains on two levels: it carries a full pallet of up to 1,000 kg on top and an empty pallet on the lower level.
Who makes the Esachain P?
The Esachain P is made by Esatroll, a robotics company based in Switzerland.
How much does the Esachain P cost?
Esatroll has not publicly announced pricing for the Esachain P. You can enquire through RobotAIGeek for current pricing.
What is the Esachain P used for?
The Esachain P is designed for material-handling, transport, and laser-guided agv that carries a full pallet above and an empty pallet below on motorised chains. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the Esachain P?
The Esachain P has a payload capacity of 1,000 kg.
How fast is the Esachain P?
The Esachain P can move at speeds of up to 4.32 km/h.
