DESCRIPTION
FP 22 is an Industrial-Robot from AFORMIC. It is built for Heavy-Load-Transportation, Intralogistics, Material-Handling. Key figures: 2343 kg, 2000 kg payload.
FP 22 is AFORMIC's large heavy-duty underride AMR, engineered for loads of up to 2 t, with four omnidirectional drives and bumpers on all four sides. It measures 4330 x 1630 x 434 mm, weighs 2343 kg, carries 2000 kg, lifts 40 mm and travels at up to 1.5 m/s with +/-10 mm positioning accuracy. Drive: omnidirectional (4 x 1 kW). It navigates by lidar SLAM using safety laser scanners with a 360-degree field of view, and is managed by AFORMIC's QURSOR fleet platform, which handles task allocation, path planning, traffic and KANBAN workflows. Power comes from a Li-Ion 280 Ah, 48 V battery.
FEATURES
- Payload: 2000 kg (4,400 lb)
- Dimensions (LxWxH): 4330 x 1630 x 434 mm (170.5 × 64.2 × 17.1 in)
- Lifting height: 40 mm (1.6 in)
- Weight: 2343 kg (5,170 lb)
- Max speed: 1.5 m/s (4.9 ft/s)
- Drive: omnidirectional
- drive power 4 x 1 kW
- Positioning accuracy +/- 1.0 cm (0.4 in)
- Safety: Laser scanner field of view: 360° Sick Micro Scanners: 4 units Emergency push buttons: 10 units Blue spot lamp: 2 units Four bumpers, one on each side of the vehicle
- Battery: Li-Ion 280 Ah, 48 V
- Lidar SLAM navigation
- no floor tape, wires or markers
- Managed by the QURSOR fleet management platform
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 2343 kg |
|---|---|
| Dimensions | L 4.33 m × W 1.63 m × H 434 mm |
| Payload | 2000 kg |
| Repeatability | ±10 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Actuators | omnidirectional (4 x 1 kW) |
| Power | |
| Battery Life | Li-Ion 280 Ah, 48 V |
| Sensing & Compute | |
| Sensors | SICK safety laser scanners (360-degree field), lidar SLAM navigation, safety bumpers |
| Connectivity | Wireless link to QURSOR fleet manager |
| Software / AI | AFORMIC QURSOR fleet management |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 2343 kg |
|---|---|
| Dimensions | L 4.33 m × W 1.63 m × H 434 mm |
| Payload | 2000 kg |
| Repeatability | ±10 mm |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Actuators | omnidirectional (4 x 1 kW) |
| Power | |
| Battery Life | Li-Ion 280 Ah, 48 V |
| Sensing & Compute | |
| Sensors | SICK safety laser scanners (360-degree field), lidar SLAM navigation, safety bumpers |
| Connectivity | Wireless link to QURSOR fleet manager |
| Software / AI | AFORMIC QURSOR fleet management |
Images
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the FP 22?
FP 22 is AFORMIC's large heavy-duty underride AMR, engineered for loads of up to 2 t, with four omnidirectional drives and bumpers on all four sides. It measures 4330 x 1630 x 434 mm, weighs 2343 kg, carries 2000 kg, lifts 40 mm and travels at up to 1.5 m/s with +/-10 mm positioning accuracy.
Who makes the FP 22?
The FP 22 is made by AFORMIC, a robotics company based in Poland.
How much does the FP 22 cost?
AFORMIC has not publicly announced pricing for the FP 22. You can enquire through RobotAIGeek for current pricing.
What is the FP 22 used for?
The FP 22 is designed for heavy-load-transportation, intralogistics, material-handling, and transport. It is used in automotive, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the FP 22?
The FP 22 has a payload capacity of 2,000 kg.
How much does the FP 22 weigh?
The FP 22 weighs 2,343 kg.
How fast is the FP 22?
The FP 22 can move at speeds of up to 5.4 km/h.
