DESCRIPTION
Full-size humanoid robot featuring high-torque integrated joints for strong limb explosive power, enabling dynamic full-body motion control across complex terrains.
FEATURES
- Height: 169 cm, Weight: 62 kg, DOF: 43, Single arm max payload: >=4 kg, Dual arm payload: >=8 kg, Repeatability: <0.1 mm, Max end-effector linear speed: 1 m/s, Max speed: 6 km/h
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 64.5 kg |
|---|---|
| Dimensions | H 1.7 m |
| Payload | 8 kg |
| Repeatability | ±0.1 mm |
| Materials | aluminium-magnesium alloy structure |
| Mobility | |
| Movement Type | Bipedal |
| Degrees of Freedom | 31 |
| Speed | 6.01 km/h |
| Manipulation | High |
| Power | |
| Battery Life | >=2 h |
| Sensing & Compute | |
| Sensors | head RGBD camera, torso RGBD camera, LiDAR, 2x high-precision IMU, 4x linear microphone, 720p monocular camera, speaker |
| Connectivity | Full-body CAN FD / EtherCAT bus; Wi-Fi 6E, Bluetooth, Ethernet, 5G |
| Software / AI | Wise Kaiwu general embodied-AI platform; proprietary high-speed middleware, ROS 2 compatible |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 64.5 kg |
|---|---|
| Dimensions | H 1.7 m |
| Payload | 8 kg |
| Repeatability | ±0.1 mm |
| Materials | aluminium-magnesium alloy structure |
| Mobility | |
| Movement Type | Bipedal |
| Degrees of Freedom | 31 |
| Speed | 6.01 km/h |
| Manipulation | High |
| Power | |
| Battery Life | >=2 h |
| Sensing & Compute | |
| Sensors | head RGBD camera, torso RGBD camera, LiDAR, 2x high-precision IMU, 4x linear microphone, 720p monocular camera, speaker |
| Connectivity | Full-body CAN FD / EtherCAT bus; Wi-Fi 6E, Bluetooth, Ethernet, 5G |
| Software / AI | Wise Kaiwu general embodied-AI platform; proprietary high-speed middleware, ROS 2 compatible |
Images
martti
Image Contributions
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Embodied Tien Kung 3.0?
Full-size humanoid robot featuring high-torque integrated joints for strong limb explosive power, enabling dynamic full-body motion control across complex terrains.
Who makes the Embodied Tien Kung 3.0?
The Embodied Tien Kung 3.0 is made by Beijing Humanoid Robot Innovation Center, a robotics company based in China.
How much does the Embodied Tien Kung 3.0 cost?
Beijing Humanoid Robot Innovation Center has not publicly announced pricing for the Embodied Tien Kung 3.0. You can enquire through RobotAIGeek for current pricing.
What is the Embodied Tien Kung 3.0 used for?
The Embodied Tien Kung 3.0 is designed for assembly, palletizing, pick-and-place, and welding. It is used in others, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the Embodied Tien Kung 3.0?
The Embodied Tien Kung 3.0 has a payload capacity of 8 kg.
How much does the Embodied Tien Kung 3.0 weigh?
The Embodied Tien Kung 3.0 weighs 64.5 kg.
How fast is the Embodied Tien Kung 3.0?
The Embodied Tien Kung 3.0 can move at speeds of up to 6.01 km/h.
What is the battery life of the Embodied Tien Kung 3.0?
The Embodied Tien Kung 3.0 runs for >=2 h on a charge.
