DESCRIPTION
CX15 is an Industrial-Robot from MAXAGV. It is built for Intralogistics, Material-Handling, Transport. Key figures: 1500 kg payload.
The CX15 Small Versatile is a conveyor load-transfer AGV that loads and unloads standard industrial pallets from either side. MAXAGV builds it with a single drive and single steer (SDSS) or single drive and eccentric steer (SDES) wheel layout for manoeuvrability, and it carries up to 1,500 kg at transfer heights of 400-900 mm.\nLike all MAXAGV vehicles it navigates mainly by laser, carries a personal-safety system of emergency stops, safety laser scanners, side edges and bumpers to ISO 3691-4:2020, and runs under the Max software platform with opportunity charging when idle. Options include barcode and RFID readers and MAXAGV's DeZone and Blue Point accessories.
FEATURES
- Conveyor load transfer from either side
- Single Drive-Single Steer (SDSS) or Single Drive-Eccentric Steer (SDES)
- Unit load: EUR - CHEP - GKN pallets, containers, stillages
- Maximum weight: 1500 kg
- Transfer/lift height: 400 - 900 mm
- Battery: Wet lead-acid, gel or lithium-ion
- Charging: Opportunity charging, fast charge or battery exchange
- Options: barcode scanner - RFID - DeZone - Blue Point
- Laser navigation as standard
- magnetic, optical or wire guidance where required
- Personal safety system: emergency stops, front/rear safety laser scanners, side edges and bumpers
- ISO 3691-4:2020
- Sonix on-board controller
- managed by the Max software platform
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Payload | 1500 kg |
|---|---|
| Mobility | |
| Movement Type | Wheeled |
| Environment | Indoor production, warehouses and distribution centres |
| Sensing & Compute | |
| Sensors | safety laser scanners, navigation laser, bumpers and safety edges |
| Connectivity | Max software platform (fleet control) |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Payload | 1500 kg |
|---|---|
| Mobility | |
| Movement Type | Wheeled |
| Environment | Indoor production, warehouses and distribution centres |
| Sensing & Compute | |
| Sensors | safety laser scanners, navigation laser, bumpers and safety edges |
| Connectivity | Max software platform (fleet control) |
Images
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the CX15?
The CX15 Small Versatile is a conveyor load-transfer AGV that loads and unloads standard industrial pallets from either side. MAXAGV builds it with a single drive and single steer (SDSS) or single drive and eccentric steer (SDES) wheel layout for manoeuvrability, and it carries up to 1,500 kg at transfer heights of 400…
Who makes the CX15?
The CX15 is made by MAXAGV, a robotics company based in Sweden.
How much does the CX15 cost?
MAXAGV has not publicly announced pricing for the CX15. You can enquire through RobotAIGeek for current pricing.
What is the CX15 used for?
The CX15 is designed for intralogistics, material-handling, transport, and intralogistics. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the CX15?
The CX15 has a payload capacity of 1,500 kg.
