DESCRIPTION
Atrax is a Military from Shark Robotics. It is built for Exploration, Inspection, Monitoring. Key figures: 75 kg, 360 min runtime, 50 kg payload, 1200 mm reach, 5 degrees of freedom, released 2018.
Atrax is a compact tracked EOD and demining robot built by Shark Robotics of La Rochelle, France, for explosive ordnance disposal, counter-IED and CBRN missions. A flipper-track chassis measuring 111.5 x 48 x 39 cm lets it work inside confined urban spaces, climb obstacles up to 20 cm and hold 40-degree slopes, while a motorised arm with 1,200 mm reach and a 200 mm clamp handles suspect devices at a distance - 12 kg bent lift, 6 kg straight. The 75 kg robot carries a 50 kg payload and runs 6 hours on two UN38.3-certified lithium-ion packs, recharging in 2 h 45. Modular bays accept jammers, manipulators, a 360-degree turret and CBRN sensor trays, and the IP65 body is controlled from the Shark Station remote at roughly 1,000 m line of sight with mesh relay. Source: https://www.shark-robotics.com/atrax-demining-robot
FEATURES
- Flipper-track chassis for stairs, rubble and confined urban spaces
- Motorised manipulator arm: 1,200 mm reach, 200 mm clamp, 12 kg bent / 6 kg straight lift
- 6-hour operational autonomy from 2 x UN38.3 lithium-ion packs
- 2 h 45 recharge
- Modular bays for jammers, disruptor interface, 360-degree turret and CBRN sensor tray
- IP65 sealing
- 2 x HD arm cameras, 2,280 lm robot lighting, 2 x 380 lm arm lighting
- ~1,000 m line-of-sight control range with mesh relay, extendable a further 500 m
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 75 kg |
|---|---|
| Dimensions | L 1.11 m × W 480 mm × H 390 mm |
| Payload | 50 kg |
| Reach | 1.2 m |
| Mobility | |
| Movement Type | Wheeled |
| Degrees of Freedom | 5 |
| Environment | IP65 sealed; confined urban spaces, rubble and CBRN environments |
| Power | |
| Battery Life | 6 hours |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 75 kg |
|---|---|
| Dimensions | L 1.11 m × W 480 mm × H 390 mm |
| Payload | 50 kg |
| Reach | 1.2 m |
| Mobility | |
| Movement Type | Wheeled |
| Degrees of Freedom | 5 |
| Environment | IP65 sealed; confined urban spaces, rubble and CBRN environments |
| Power | |
| Battery Life | 6 hours |
Images
martti
martti
martti
martti
martti
martti
martti
marttiImage Contributions
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Atrax?
Atrax is a compact tracked EOD and demining robot built by Shark Robotics of La Rochelle, France, for explosive ordnance disposal, counter-IED and CBRN missions.
Who makes the Atrax?
The Atrax is made by Shark Robotics, a robotics company based in France.
How much does the Atrax cost?
Shark Robotics has not publicly announced pricing for the Atrax. You can enquire through RobotAIGeek for current pricing.
What is the Atrax used for?
The Atrax is designed for exploration, inspection, monitoring, and remote. It is used in defence and security & patrol settings.
What is the payload capacity of the Atrax?
The Atrax has a payload capacity of 50 kg and a reach of 1.2 m.
How much does the Atrax weigh?
The Atrax weighs 75 kg.
What is the battery life of the Atrax?
The Atrax runs for 6 hours on a charge.
How many degrees of freedom does the Atrax have?
The Atrax has 5 degrees of freedom.
