DESCRIPTION
The 40 t Omnidirectional Lifting AGV is a Omnidirectional Lifting AGV built by Lonyu AGV, rated to carry 40 t. Lonyu designates it LY-AU-40T-4-0A. It has a body measuring 5500 mm long, 2650 mm wide and 730 mm high and an unladen mass of 15 t. Mechanically, the chassis uses tubesheet; the drive layout is 4-drive; suspension is hydraulic. Drive is superdrive. It navigates by magnetic stripe, is commanded by manual remote. For power and motion, it runs at 96V.
FEATURES
- Rated load: 40 t
- Unladen mass: 15 t
- Body dimensions: 5500 x 2650 x 730 mm
- Chassis: Tubesheet
- Drive wheels: 4-Drive
- Drive type: Superdrive
- Navigation: Magnetic Stripe
- Control: Manual Remote
- Voltage: 96V
- Suspension: Hydraulic
- Drive-unit load rating: 15T
- Castors: 0
- Linkage mode: Single AGV
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 15000 kg |
|---|---|
| Dimensions | L 5.5 m × W 2.65 m × H 730 mm |
| Payload | 40000 kg |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 15000 kg |
|---|---|
| Dimensions | L 5.5 m × W 2.65 m × H 730 mm |
| Payload | 40000 kg |
Images
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the 40 t Omnidirectional Lifting AGV?
The 40 t Omnidirectional Lifting AGV is a Omnidirectional Lifting AGV built by Lonyu AGV, rated to carry 40 t. Lonyu designates it LY-AU-40T-4-0A. It has a body measuring 5500 mm long, 2650 mm wide and 730 mm high and an unladen mass of 15 t.
Who makes the 40 t Omnidirectional Lifting AGV?
The 40 t Omnidirectional Lifting AGV is made by Lonyu Agv.
How much does the 40 t Omnidirectional Lifting AGV cost?
Lonyu Agv has not publicly announced pricing for the 40 t Omnidirectional Lifting AGV. You can enquire through RobotAIGeek for current pricing.
What is the 40 t Omnidirectional Lifting AGV used for?
The 40 t Omnidirectional Lifting AGV is designed for transport.
What is the payload capacity of the 40 t Omnidirectional Lifting AGV?
The 40 t Omnidirectional Lifting AGV has a payload capacity of 40,000 kg.
How much does the 40 t Omnidirectional Lifting AGV weigh?
The 40 t Omnidirectional Lifting AGV weighs 15,000 kg.
