描述
Galbot G1 runs on a 360° omnidirectional-wheel chassis and extends its mechanical arm up to 1.9m with a 10kg payload, operating across heights from 0 to 2.4m.
功能特色
- 360° omnidirectional-wheel chassis, adaptive height operation (0-2.4m), 1.9m mechanical arm reach, 10kg payload, dexterous hand with modular design, multimodal perception (visual, auditory, 3D), embodied intelligence, Embosar in-house embodied intelligence system architecture, industrial protection (IP54), 6.25-inch smart interactive display, 8 hours operating time.
技術規格
已驗證| 物理參數 | |
| 重量 | 92.5 kg |
|---|---|
| 外形尺寸 | H 1.73 m |
| 負載 | 10 kg |
| 臂展 | 1.9 m |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 自由度 | 24 |
| 操作能力 | 高 |
| 作業環境 | IP54 |
| 致動器 | Legs 2 + waist 3 + neck 2 = 7 DoF, dual arms 7x2 = 14 DoF, four chassis drive wheels = 24 total; 650 mm torso lift; 710 mm arm length shoulder to wrist |
| 電源與續航 | |
| 續航時間 | 8 h |
| 感知與計算 | |
| 感測器 | head binocular camera, 2x wrist depth cameras, 2x wrist six-axis force sensors, 4x torso RGB cameras, torso IMU, chassis 3D LiDAR, 8x chassis ultrasonic sensors, chassis IMU, 2x linear 4-mic arrays, 5.5-inch 1920x1080 touchscreen |
| 連線方式 | Wi-Fi 2.4/5 GHz; Bluetooth |
| 軟體 / AI | Embosar in-house embodied-intelligence system architecture; multimodal visual and auditory perception with intent understanding and voice interaction |
技術規格
已驗證| 物理參數 | |
| 重量 | 92.5 kg |
|---|---|
| 外形尺寸 | H 1.73 m |
| 負載 | 10 kg |
| 臂展 | 1.9 m |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 自由度 | 24 |
| 操作能力 | 高 |
| 作業環境 | IP54 |
| 致動器 | Legs 2 + waist 3 + neck 2 = 7 DoF, dual arms 7x2 = 14 DoF, four chassis drive wheels = 24 total; 650 mm torso lift; 710 mm arm length shoulder to wrist |
| 電源與續航 | |
| 續航時間 | 8 h |
| 感知與計算 | |
| 感測器 | head binocular camera, 2x wrist depth cameras, 2x wrist six-axis force sensors, 4x torso RGB cameras, torso IMU, chassis 3D LiDAR, 8x chassis ultrasonic sensors, chassis IMU, 2x linear 4-mic arrays, 5.5-inch 1920x1080 touchscreen |
| 連線方式 | Wi-Fi 2.4/5 GHz; Bluetooth |
| 軟體 / AI | Embosar in-house embodied-intelligence system architecture; multimodal visual and auditory perception with intent understanding and voice interaction |
圖片
martti
martti
martti
martti
martti圖片貢獻
機器人論壇
正在載入論壇...
評分
常見問題
What is the Galbot G1?
Galbot G1 runs on a 360° omnidirectional-wheel chassis and extends its mechanical arm up to 1.9m with a 10kg payload, operating across heights from 0 to 2.4m.
Who makes the Galbot G1?
The Galbot G1 is made by Galbot (Beijing Galaxy General Robot Co., Ltd.), a robotics company based in China.
How much does the Galbot G1 cost?
Galbot (Beijing Galaxy General Robot Co., Ltd.) has not publicly announced pricing for the Galbot G1. You can enquire through RobotAIGeek for current pricing.
What is the Galbot G1 used for?
The Galbot G1 is designed for 組裝, 清潔, 拾放, and 送貨. It is used in 醫療保健, 住宅, 物流, and 製造業 settings.
What is the payload capacity of the Galbot G1?
The Galbot G1 has a payload capacity of 10 kg and a reach of 1.9 m.
How much does the Galbot G1 weigh?
The Galbot G1 weighs 92.5 kg.
What is the battery life of the Galbot G1?
The Galbot G1 runs for 8 h on a charge.
How many degrees of freedom does the Galbot G1 have?
The Galbot G1 has 24 degrees of freedom.
