DESCRIPTION
WUBA Rescue & Support Robotic Dog is a Security from WUBA Intelligent Technology. It is built for Inspection, Transport, Emergency equipment delivery. Key figures: 75 kg, 120 min runtime, 20 kg payload.
The Rescue and Support dog is the courier of WUBA's duty range: its job is to carry 20 kg or more of rescue kits, oxygen masks, breaching tools and other emergency equipment to people who need it, across ground a wheeled vehicle cannot cross. It is the fastest machine on the large quadruped platform at 12 km/h or more — six times the walking speed of the patrol and riot variants — which matters when the payload is oxygen. The rest matches its siblings: up to 1100 mm long, 30-degree slopes and stairs, 20 cm steps, IP65 sealing, two hours or more of endurance, and radio, WiFi or optional cellular links across a -20 to 50 degree Celsius range.
FEATURES
- Full-system weight 75 kg or less
- Standing dimensions up to 1100 (L) x 490 (W) x 1000 (H) mm
- Payload capacity 20 kg or more, for rescue kits, oxygen masks, breaching tools and other emergency equipment
- Maximum speed 12 km/h or more, the fastest on this platform
- Maximum slope climbing incline 30 degrees or more
- stair-climbing angle 30 degrees or more
- Maximum step height 20 cm or more
- Endurance 2 hours or more
- IP65 protection rating
- Operating temperature -20 to 50 degrees Celsius
- Communication options: 4G, 5G, WiFi and radio (optional)
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 75 kg |
|---|---|
| Dimensions | L 1.1 m × W 490 mm × H 1 m |
| Payload | 20 kg |
| Mobility | |
| Movement Type | Quadruped |
| Speed | 11.99 km/h |
| Environment | Disaster sites and rough terrain; IP65; -20 to 50 degrees Celsius |
| Actuators | Large legged quadruped with an equipment-carrying payload box |
| Power | |
| Battery Life | ≥2 h |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 75 kg |
|---|---|
| Dimensions | L 1.1 m × W 490 mm × H 1 m |
| Payload | 20 kg |
| Mobility | |
| Movement Type | Quadruped |
| Speed | 11.99 km/h |
| Environment | Disaster sites and rough terrain; IP65; -20 to 50 degrees Celsius |
| Actuators | Large legged quadruped with an equipment-carrying payload box |
| Power | |
| Battery Life | ≥2 h |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the WUBA Rescue & Support Robotic Dog?
The Rescue and Support dog is the courier of WUBA's duty range: its job is to carry 20 kg or more of rescue kits, oxygen masks, breaching tools and other emergency equipment to people who need it, across ground a wheeled vehicle cannot cross.
Who makes the WUBA Rescue & Support Robotic Dog?
The WUBA Rescue & Support Robotic Dog is made by WUBA Intelligent Technology, a robotics company based in China.
How much does the WUBA Rescue & Support Robotic Dog cost?
WUBA Intelligent Technology has not publicly announced pricing for the WUBA Rescue & Support Robotic Dog. You can enquire through RobotAIGeek for current pricing.
What is the WUBA Rescue & Support Robotic Dog used for?
The WUBA Rescue & Support Robotic Dog is designed for inspection, transport, emergency equipment delivery, and search and rescue support. It is used in energy, healthcare, and security & patrol settings.
What is the payload capacity of the WUBA Rescue & Support Robotic Dog?
The WUBA Rescue & Support Robotic Dog has a payload capacity of 20 kg.
How much does the WUBA Rescue & Support Robotic Dog weigh?
The WUBA Rescue & Support Robotic Dog weighs 75 kg.
How fast is the WUBA Rescue & Support Robotic Dog?
The WUBA Rescue & Support Robotic Dog can move at speeds of up to 11.99 km/h.
What is the battery life of the WUBA Rescue & Support Robotic Dog?
The WUBA Rescue & Support Robotic Dog runs for ≥2 h on a charge.
