NEXWISE Zhifang X1

SecurityChinaChinaReleased
NEXWISE Zhifang X1
Compare
Uses:
InspectionMonitoringPolice patrolsecurity duty at key sitesindustrial inspectionemergency rescuehazardous target identification and restraint
Price:
Not announced

DESCRIPTION

NEXWISE Zhifang X1 is a Security from Nexwise Intelligence. It is built for Inspection, Monitoring, Police patrol. Key figures: 72 kg, 180 min runtime.

The Zhifang X1 is Nexwise's flagship net-capture quadruped, and it is built around a capability almost nothing else in the category has: an electromagnetic net launcher that fires an ultra-high-molecular-weight polyethylene net to restrain a target at 5 to 10 metres without contact. Nexwise claims it as the first electromagnetic net-capturing system integrated onto a quadruped robot. The net deploys to 2.4 by 2.4 metres with a mesh of 150 mm or less, and the launcher holds more than 500 shots over its life with at least 50 per charge. Firing is not left to the operator alone — an onboard edge-computing platform drives a vision system that locks automatically onto the target area to improve capture accuracy, and the shot can be triggered on-site, remotely or by voice. The machine underneath is a serious patrol robot in its own right: 72 kg, IP67 on the main body with IP55 on the upper payload, more than three hours and ten kilometres of endurance, 4 m/s, and a 45-degree climbing angle. It patrols predefined routes autonomously and returns to charge itself, recognises faces, licence plates, weapon-carrying behaviour and fire or smoke through multimodal models, and escalates to a command platform in real time. Nexwise aims it at police patrol, security duty, industrial inspection and emergency rescue.

FEATURES

  • First electromagnetic net-capturing system integrated on a quadruped robot, on the manufacturer's claim
  • 1000 x 470 x 1020 mm upright and 1130 x 470 x 590 mm prone, at 72 kg
  • Main body rated IP67 with the upper payload rated IP55
  • Endurance of more than 3 hours and continuous travel range of more than 10 km
  • Maximum speed of 4 m/s
  • Maximum climbing angle of 45 degrees and maximum step height of 20 cm
  • Operating temperature from -20 to 55 degrees Celsius
  • Ultra-high molecular weight polyethylene net with an effective capture range of 5 to 10 m
  • Deployed net size of 2.4 x 2.4 m with a mesh size of 150 mm or less
  • More than 500 shots maximum firing count, and at least 50 shots per charge
  • Automatic targeting: edge computing drives a vision system that locks onto key target areas to improve capture accuracy
  • Triple net-capture control modes: on-site, remote and voice-activated
  • Autonomous patrol along predefined routes with automatic charging, plus accompanied patrol alongside duty personnel
  • Real-time mapping, dynamic path planning and intelligent obstacle avoidance
  • Multimodal AI recognition covering faces, licence plates, weapon-carrying behaviour and fire or smoke detection
  • Panoramic surveillance with automatic recording, real-time transmission and post-event review
  • Real-time graded alerts pushed to the command platform
  • High-power loudspeaker for voice warning and public address, multi-mode warning light, and a one-touch SOS button
  • Payload options including a dual-light gimbal, robotic arm, gas detection module, HD camera, ultrasonic radar and portable surveillance camera
  • Traverses complex terrain including sand, gravel and muddy ground

TECHNICAL SPECIFICATIONS

Verified
Physical
Weight72 kg
DimensionsL 1 m × W 470 mm × H 1.02 m
Mobility
Movement TypeQuadruped
Speed14.4 km/h
EnvironmentOutdoor patrol over sand, gravel and muddy ground; main body IP67, upper payload IP55; -20 to 55 degrees Celsius
ActuatorsQuadruped chassis carrying an electromagnetic net launcher on a modular upper payload deck
Power
Battery Life>3 h
Sensing & Compute
SensorsHD camera, ultrasonic radar, portable surveillance camera
Software / AIAutonomous navigation with real-time mapping, dynamic path planning, obstacle avoidance and auto-charging; multimodal large-model recognition; edge-computing automatic targeting for net capture; closed-loop command-platform alerting
Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

FREQUENTLY ASKED QUESTIONS

What is the NEXWISE Zhifang X1?

The Zhifang X1 is Nexwise's flagship net-capture quadruped, and it is built around a capability almost nothing else in the category has: an electromagnetic net launcher that fires an ultra-high-molecular-weight polyethylene net to restrain a target at 5 to 10 metres without contact.

Who makes the NEXWISE Zhifang X1?

The NEXWISE Zhifang X1 is made by Nexwise Intelligence, a robotics company based in China.

How much does the NEXWISE Zhifang X1 cost?

Nexwise Intelligence has not publicly announced pricing for the NEXWISE Zhifang X1. You can enquire through RobotAIGeek for current pricing.

What is the NEXWISE Zhifang X1 used for?

The NEXWISE Zhifang X1 is designed for inspection, monitoring, police patrol, and security duty at key sites. It is used in energy, manufacturing, and security & patrol settings.

How much does the NEXWISE Zhifang X1 weigh?

The NEXWISE Zhifang X1 weighs 72 kg.

How fast is the NEXWISE Zhifang X1?

The NEXWISE Zhifang X1 can move at speeds of up to 14.4 km/h.

What is the battery life of the NEXWISE Zhifang X1?

The NEXWISE Zhifang X1 runs for >3 h on a charge.
