WUBA Emergency Detection & Reconnaissance Robot Dog
DESCRIPTION
WUBA Emergency Detection & Reconnaissance Robot Dog is a Security from WUBA Intelligent Technology. It is built for Inspection, Monitoring, Disaster reconnaissance. Key figures: 75 kg, 120 min runtime, 75 kg payload.
The Emergency Detection and Reconnaissance dog is built to go in first and report back, and its standard payload says exactly that: a laser scanner, a gas sensor, a voice intercom, a GNSS receiver, a 360-degree panoramic camera and a mesh radio module. The mesh radio is the telling inclusion — in a collapsed structure or an underground space there is no cellular coverage and no WiFi infrastructure, so a self-forming mesh between units and the operator is the only link that survives, and WUBA lists WiFi and mesh radio as this model's only communication modes rather than offering cellular at all. It weighs 75 kg or less with its rated payload fitted, moves at 7.2 km/h or more, climbs 30-degree gradients and stairs, steps over 20 cm, is sealed to IP65 and runs two hours or more from -20 to 50 degrees Celsius.
FEATURES
- Overall weight with rated payload 75 kg or less
- Standing dimensions up to 1100 (L) x 490 (W) x 1000 (H) mm
- Maximum travel speed 7.2 km/h or more
- Maximum climb gradient 30 degrees or more
- maximum stair climb incline 30 degrees or more
- Maximum climbable step height 20 cm or more
- Runtime 2 hours or more
- IP65 protection rating
- Operating ambient temperature -20 to 50 degrees Celsius
- Communication modes: WiFi and mesh radio module, with no cellular option listed
- Standard payload configuration: laser scanner, gas sensor, voice intercom module, GNSS receiver, 360 degree panoramic camera and mesh radio module
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 75 kg |
|---|---|
| Dimensions | L 1.1 m × W 490 mm × H 1 m |
| Payload | 75 kg |
| Mobility | |
| Movement Type | Quadruped |
| Speed | 7.2 km/h |
| Environment | Disaster sites, hazardous atmospheres and confined spaces; IP65; -20 to 50 degrees Celsius |
| Actuators | Large legged quadruped with a fixed reconnaissance sensor payload |
| Power | |
| Battery Life | ≥2 h |
| Sensing & Compute | |
| Sensors | laser scanner, gas sensor, 360 degree panoramic camera, GNSS receiver, mesh radio module |
