DESCRIPTION
WUBA Patrol & Security Robot Dog is a Security from WUBA Intelligent Technology. It is built for Inspection, Monitoring, Public security patrol. Key figures: 75 kg, 120 min runtime.
The Patrol & Security dog is the standard-issue machine of WUBA's large quadruped platform, and what distinguishes it is how much comes fitted as standard: a surveillance ball, edge computing module, voice intercom, networking, GNSS, a following module, a protective module and a 360-degree panoramic camera. That is a complete patrol kit rather than a base to build on, which matters for a buyer who wants a working capability rather than an integration project. Thermal imagers and gas detectors are available on top. At up to 75 kg and 1100 mm long it covers 12 km per deployment at 2 m/s, climbs 30-degree slopes and stairs, steps over 22 cm obstacles, and endures two hours or more across a -20 to 55 degree Celsius range. Communications are flexible by design — radio, WiFi or optional 4G and 5G — which matters where cellular coverage cannot be assumed.
FEATURES
- Total weight 75 kg or less
- Standing dimensions up to 1100 (L) x 490 (W) x 1000 (H) mm
- Range 12 km
- endurance 2 hours or more
- Maximum speed 2 m/s
- Step climbing height 22 cm or more
- maximum slope climbing incline 30 degrees or more
- stair-climbing angle 30 degrees or more
- Working temperature -20 to 55 degrees Celsius
- Communication options: radio, WiFi, and optional 4G and 5G
- Standard top configuration: surveillance ball, edge computing module, voice intercom module, networking, GNSS, following module, protective module and 360 degree panoramic camera
- Optional top configuration: thermal imagers, gas detectors and similar
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 75 kg |
|---|---|
| Dimensions | L 1.1 m × W 490 mm × H 1 m |
| Mobility | |
| Movement Type | Quadruped |
| Speed | 7.2 km/h |
| Environment | Outdoor patrol; -20 to 55 degrees Celsius |
| Actuators | Large legged quadruped with a modular top payload deck |
| Power | |
| Battery Life | ≥2 h |
| Sensing & Compute | |
| Sensors | surveillance ball, 360 degree panoramic camera, GNSS, thermal imager (optional), gas detector (optional) |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 75 kg |
|---|---|
| Dimensions | L 1.1 m × W 490 mm × H 1 m |
| Mobility | |
| Movement Type | Quadruped |
| Speed | 7.2 km/h |
| Environment | Outdoor patrol; -20 to 55 degrees Celsius |
| Actuators | Large legged quadruped with a modular top payload deck |
| Power | |
| Battery Life | ≥2 h |
| Sensing & Compute | |
| Sensors | surveillance ball, 360 degree panoramic camera, GNSS, thermal imager (optional), gas detector (optional) |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the WUBA Patrol & Security Robot Dog?
The Patrol & Security dog is the standard-issue machine of WUBA's large quadruped platform, and what distinguishes it is how much comes fitted as standard: a surveillance ball, edge computing module, voice intercom, networking, GNSS, a following module, a protective module and a 360-degree panoramic camera.
Who makes the WUBA Patrol & Security Robot Dog?
The WUBA Patrol & Security Robot Dog is made by WUBA Intelligent Technology, a robotics company based in China.
How much does the WUBA Patrol & Security Robot Dog cost?
WUBA Intelligent Technology has not publicly announced pricing for the WUBA Patrol & Security Robot Dog. You can enquire through RobotAIGeek for current pricing.
What is the WUBA Patrol & Security Robot Dog used for?
The WUBA Patrol & Security Robot Dog is designed for inspection, monitoring, public security patrol, and industrial site security. It is used in energy, manufacturing, and security & patrol settings.
How much does the WUBA Patrol & Security Robot Dog weigh?
The WUBA Patrol & Security Robot Dog weighs 75 kg.
How fast is the WUBA Patrol & Security Robot Dog?
The WUBA Patrol & Security Robot Dog can move at speeds of up to 7.2 km/h.
What is the battery life of the WUBA Patrol & Security Robot Dog?
The WUBA Patrol & Security Robot Dog runs for ≥2 h on a charge.
