DESCRIPTION
VTA20/30 is an Industrial-Robot from i-Cow. It is built for Intralogistics, Material-Handling, Pallet-Transportation. Key figures: 867 kg, 2000 kg payload.
The VTA20/30 is a pallet-transport mobile robot from i-Cow (Muniu Liuma), an autonomous forklift that picks up and carries pallets along floor-level routes between production lines, docks and storage. It is rated for 2,000 kg at a 600 mm load centre, lifts to 210 mm, weighs 867 kg and measures 2,288 x 900 x 2,230 mm. Its forks measure 55 x 165 x 1150 mm (thickness x width x length). It travels at up to 1.5 m/s with ±10 mm positioning accuracy and a minimum turning radius of 1916 mm, runs on a 24 V, 210 Ah battery, and is dispatched with i-Cow's other AGVs through its multi-vehicle scheduling system, which runs mixed fleets on one shared map and supports the VDA 5050 interface. The figures above are for the VTA20; the same page lists VTA30 variants with different capacities.
FEATURES
- Rated load 2,000 kg at 600 mm load centre
- Lift height 210 mm
- Overall dimensions 2288 x 900 x 2230 mm (L x W x H)
- Service weight 867 kg
- Forks 55/165/1150 mm (e/s/l)
- Turning radius 1916 mm
- Travel speed 0-1.5 m/s
- positioning accuracy ±10 mm
- Battery 24 V / 210 Ah
- Multi-vehicle scheduling on one shared map
- VDA 5050 interface
- Variants on page: VTA20, VTA30
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 867 kg |
|---|---|
| Dimensions | L 2.29 m × W 900 mm × H 2.23 m |
| Payload | 2000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Connectivity | Fleet scheduling system; VDA 5050 |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 867 kg |
|---|---|
| Dimensions | L 2.29 m × W 900 mm × H 2.23 m |
| Payload | 2000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Connectivity | Fleet scheduling system; VDA 5050 |
Images
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the VTA20/30?
The VTA20/30 is a pallet-transport mobile robot from i-Cow (Muniu Liuma), an autonomous forklift that picks up and carries pallets along floor-level routes between production lines, docks and storage. It is rated for 2,000 kg at a 600 mm load centre, lifts to 210 mm, weighs 867 kg and measures 2,288 x 900 x 2,230 mm.
Who makes the VTA20/30?
The VTA20/30 is made by i-Cow, a robotics company based in China.
How much does the VTA20/30 cost?
i-Cow has not publicly announced pricing for the VTA20/30. You can enquire through RobotAIGeek for current pricing.
What is the VTA20/30 used for?
The VTA20/30 is designed for intralogistics, material-handling, pallet-transportation, and transport. It is used in automotive, electronics, energy, and warehouse & logistics settings.
What is the payload capacity of the VTA20/30?
The VTA20/30 has a payload capacity of 2,000 kg.
How much does the VTA20/30 weigh?
The VTA20/30 weighs 867 kg.
How fast is the VTA20/30?
The VTA20/30 can move at speeds of up to 5.4 km/h.
