DESCRIPTION
VPE01E is an Industrial-Robot from i-Cow. It is built for Intralogistics, Material-Handling, Transport. Key figures: 135 kg, 100 kg payload.
The VPE01E is a drum-clamp towing mobile robot from i-Cow (Muniu Liuma), an autonomous mobile robot that clamps and tows round drums and reels with its clamp arms. It is rated for 100 kg, weighs 135 kg and measures 1,859 x 1,170 x 2,350 mm. The clamp arms handle drums of 1000 mm diameter. It travels at up to 1.2 m/s with ±10 mm positioning accuracy and a minimum turning radius of 1017 mm, runs on a 48 V, 30 Ah battery, and is dispatched with i-Cow's other AGVs through its multi-vehicle scheduling system, which runs mixed fleets on one shared map and supports the VDA 5050 interface.
FEATURES
- Rated load 100 kg
- Overall dimensions 1859 x 1170 x 2350 mm (L x W x H)
- Service weight 135 kg
- Drum diameter 1000 mm
- Turning radius 1017 mm
- Travel speed 0-1.2 m/s
- positioning accuracy ±10 mm
- Battery 48 V / 30 Ah
- Multi-vehicle scheduling on one shared map
- VDA 5050 interface
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 135 kg |
|---|---|
| Dimensions | L 1.86 m × W 1.17 m × H 2.35 m |
| Payload | 100 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 4.32 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Connectivity | Fleet scheduling system; VDA 5050 |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 135 kg |
|---|---|
| Dimensions | L 1.86 m × W 1.17 m × H 2.35 m |
| Payload | 100 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 4.32 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Connectivity | Fleet scheduling system; VDA 5050 |
Images
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the VPE01E?
The VPE01E is a drum-clamp towing mobile robot from i-Cow (Muniu Liuma), an autonomous mobile robot that clamps and tows round drums and reels with its clamp arms. It is rated for 100 kg, weighs 135 kg and measures 1,859 x 1,170 x 2,350 mm. The clamp arms handle drums of 1000 mm diameter.
Who makes the VPE01E?
The VPE01E is made by i-Cow, a robotics company based in China.
How much does the VPE01E cost?
i-Cow has not publicly announced pricing for the VPE01E. You can enquire through RobotAIGeek for current pricing.
What is the VPE01E used for?
The VPE01E is designed for intralogistics, material-handling, transport, and autonomous pallet and material handling. It is used in automotive, electronics, energy, and warehouse & logistics settings.
What is the payload capacity of the VPE01E?
The VPE01E has a payload capacity of 100 kg.
How much does the VPE01E weigh?
The VPE01E weighs 135 kg.
How fast is the VPE01E?
The VPE01E can move at speeds of up to 4.32 km/h.
