DESCRIPTION
VLR12/15M is an Industrial-Robot from i-Cow. It is built for Intralogistics, Lifting, Material-Handling. Key figures: 1800 kg, 1200 kg payload.
The VLR12/15M is a mini reach mobile robot from i-Cow (Muniu Liuma), an autonomous forklift that extends its mast forward to place and retrieve pallets in high racking within narrower aisles. It is rated for 1,200 kg at a 500 mm load centre, lifts to 2700 mm, weighs 1,800 kg and measures 2,889 x 990 x 2,082 mm. Its forks measure 44 x 123 x 1000 mm (thickness x width x length). It travels at up to 1.5 m/s with ±10 mm positioning accuracy and a minimum turning radius of 1701 mm, runs on a 24 V, 200 Ah battery, and is dispatched with i-Cow's other AGVs through its multi-vehicle scheduling system, which runs mixed fleets on one shared map and supports the VDA 5050 interface. The figures above are for the VLR12M; the same page lists VLR15M variants with different capacities.
FEATURES
- Rated load 1,200 kg at 500 mm load centre
- Lift height 2700 mm
- Overall dimensions 2889 x 990 x 2082 mm (L x W x H)
- Service weight 1,800 kg
- Forks 44/123/1000 mm (e/s/l)
- Turning radius 1701 mm
- Travel speed 0-1.5 m/s
- positioning accuracy ±10 mm
- Battery 24 V / 200 Ah
- Multi-vehicle scheduling on one shared map
- VDA 5050 interface
- Variants on page: VLR12M, VLR15M
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 1800 kg |
|---|---|
| Dimensions | L 2.89 m × W 990 mm × H 2.08 m |
| Payload | 1200 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Connectivity | Fleet scheduling system; VDA 5050 |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 1800 kg |
|---|---|
| Dimensions | L 2.89 m × W 990 mm × H 2.08 m |
| Payload | 1200 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor factories and warehouses |
| Sensing & Compute | |
| Connectivity | Fleet scheduling system; VDA 5050 |
Images
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the VLR12/15M?
The VLR12/15M is a mini reach mobile robot from i-Cow (Muniu Liuma), an autonomous forklift that extends its mast forward to place and retrieve pallets in high racking within narrower aisles. It is rated for 1,200 kg at a 500 mm load centre, lifts to 2700 mm, weighs 1,800 kg and measures 2,889 x 990 x 2,082 mm.
Who makes the VLR12/15M?
The VLR12/15M is made by i-Cow, a robotics company based in China.
How much does the VLR12/15M cost?
i-Cow has not publicly announced pricing for the VLR12/15M. You can enquire through RobotAIGeek for current pricing.
What is the VLR12/15M used for?
The VLR12/15M is designed for intralogistics, lifting, material-handling, and pallet-transportation. It is used in automotive, electronics, energy, and warehouse & logistics settings.
What is the payload capacity of the VLR12/15M?
The VLR12/15M has a payload capacity of 1,200 kg.
How much does the VLR12/15M weigh?
The VLR12/15M weighs 1,800 kg.
How fast is the VLR12/15M?
The VLR12/15M can move at speeds of up to 5.4 km/h.
