DESCRIPTION
UFACTORY xArm 5 is a Collaborative-Robot from UFactory. It is built for Assembly, Machine-Tending, Pick-and-place. Key figures: 11.3 kg, 3 kg payload, 700 mm reach, 5 degrees of freedom, price $5,299–$5,494, released 2018.
The UFACTORY xArm 5 is a 5-axis collaborative robot designed for industrial automation tasks. It offers a 3 kg payload and a 700 mm reach with ±0.1 mm repeatability. The robot is crafted from carbon fiber, weighing 11.3 kg, and features industrial-grade harmonic drives and servomotors for 24/7 operation. It supports hand teaching and includes collision detection for safety.
FEATURES
- 5 degrees of freedom
- 3 kg payload
- 700 mm reach
- ±0.1 mm repeatability
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 11.3 kg |
|---|---|
| Payload | 3 kg |
| Reach | 700 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 5 |
| Speed | 3.6 km/h |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 11.3 kg |
|---|---|
| Payload | 3 kg |
| Reach | 700 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 5 |
| Speed | 3.6 km/h |
Images
martti
martti
martti
marttiImage Contributions
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the UFACTORY xArm 5?
The UFACTORY xArm 5 is a 5-axis collaborative robot designed for industrial automation tasks. It offers a 3 kg payload and a 700 mm reach with ±0.1 mm repeatability. The robot is crafted from carbon fiber, weighing 11.3 kg, and features industrial-grade harmonic drives and servomotors for 24/7 operation.
Who makes the UFACTORY xArm 5?
The UFACTORY xArm 5 is made by UFactory, a robotics company based in China.
How much does the UFACTORY xArm 5 cost?
Pricing for the UFACTORY xArm 5 ranges from $5,299 to $5,494.
What is the UFACTORY xArm 5 used for?
The UFACTORY xArm 5 is designed for assembly, machine-tending, pick-and-place, and research. It is used in research, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the UFACTORY xArm 5?
The UFACTORY xArm 5 has a payload capacity of 3 kg and a reach of 700 mm.
How much does the UFACTORY xArm 5 weigh?
The UFACTORY xArm 5 weighs 11.3 kg.
How fast is the UFACTORY xArm 5?
The UFACTORY xArm 5 can move at speeds of up to 3.6 km/h.
How many degrees of freedom does the UFACTORY xArm 5 have?
The UFACTORY xArm 5 has 5 degrees of freedom.
