DESCRIPTION
SAFELOG L2 core is a Mobile-Robots from SAFELOG. It is built for Intralogistics, Material-Handling, Pallet-Transportation. Key figures: 243 kg, 102 min runtime, 1500 kg payload.
The L2 core is the base model of SAFELOG's heavy L2 series for pallets and pallet cages of up to 1,500 kg. Omnidirectional travel and the ability to turn on the spot keep it agile in confined spaces despite the high payload. Without active load handling, it is used as a transport robot for goods-to-person processes or, with a custom superstructure such as a conveyor, as a mobile assembly platform. Per its datasheet it measures 1,200 x 700 x 310 mm, weighs 243 kg, drives at up to 1.0 m/s loaded (1.6 m/s empty), positions to +/-5 mm and runs about 1.7 hours under load on two 24 V 42 Ah LiFePO4 packs, or up to about 3.4 hours with four.
FEATURES
- Omnidirectional travel
- turns on the spot
- Top load 1,500 kg - pallets and pallet cages, goods-to-person or assembly platform
- No active load handling (custom superstructures, e.g. conveyors)
- Speed 0.02-1.0 m/s (1.6 m/s empty)
- Localization: magnetic track, RFID, inductive sensor
- LiDAR and grid codes optional
- optional 3D camera
- LiFePO4 24 V, 2 x 42 Ah (3-4 packs optional)
- 30 min charge
- 1.7 h with load (up to 3.4 h)
- Size 1,200 x 700 x 310 mm
- 243 kg
- CE, FCC
- Agent-based swarm control (SAFELOG IntelliAgent) over Wi-Fi - no central control station needed
- VDA 5050-ready for third-party fleet managers
- Inductive in-process charging
- LiFePO4 batteries
- Operating range +5 to +35 C
- VDI 2510 floors
- 24/7 operation
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 243 kg |
|---|---|
| Dimensions | L 1.2 m × W 700 mm × H 310 mm |
| Payload | 1500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Indoor production and warehouse floors (+5 to 35 C, VDI 2510) |
| Power | |
| Battery Life | 102 min |
| Sensing & Compute | |
| Sensors | safety laser scanner, RFID / grid-code / magnetic-track sensors |
| Connectivity | Wi-Fi; VDA 5050 |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 243 kg |
|---|---|
| Dimensions | L 1.2 m × W 700 mm × H 310 mm |
| Payload | 1500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Indoor production and warehouse floors (+5 to 35 C, VDI 2510) |
| Power | |
| Battery Life | 102 min |
| Sensing & Compute | |
| Sensors | safety laser scanner, RFID / grid-code / magnetic-track sensors |
| Connectivity | Wi-Fi; VDA 5050 |
Images
martti
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the SAFELOG L2 core?
The L2 core is the base model of SAFELOG's heavy L2 series for pallets and pallet cages of up to 1,500 kg. Omnidirectional travel and the ability to turn on the spot keep it agile in confined spaces despite the high payload.
Who makes the SAFELOG L2 core?
The SAFELOG L2 core is made by SAFELOG, a robotics company based in Germany.
How much does the SAFELOG L2 core cost?
SAFELOG has not publicly announced pricing for the SAFELOG L2 core. You can enquire through RobotAIGeek for current pricing.
What is the SAFELOG L2 core used for?
The SAFELOG L2 core is designed for intralogistics, material-handling, pallet-transportation, and transport. It is used in automotive, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the SAFELOG L2 core?
The SAFELOG L2 core has a payload capacity of 1,500 kg.
How much does the SAFELOG L2 core weigh?
The SAFELOG L2 core weighs 243 kg.
How fast is the SAFELOG L2 core?
The SAFELOG L2 core can move at speeds of up to 5.76 km/h.
What is the battery life of the SAFELOG L2 core?
The SAFELOG L2 core runs for about 102 minutes on a charge.
