DESCRIPTION
The Kepler Qilin is a heavy-duty long-endurance quadruped built around the company's proprietary planetary roller screw actuators — 12 of them at 27,000 N peak thrust — giving a static payload capacity of over 600 kg and a rated dynamic payload of 150 kg on a 270 kg body. It runs 4.5-8 hours per charge on a 300 V / 21 Ah platform, climbs 45° inclines, carries an IPX5 whole-machine rating with IP67 core components, and walks, trots, crosses obstacles and wades for industrial transport, mountain logistics and disaster-rescue missions.
FEATURES
- Static payload over 600 kg, near one tonne full rated
- 12x planetary roller screw actuators at 27,000 N
- 8-hour endurance at full load
- 45° max climbing incline
- IPX5 whole machine / IP67 core components
- ultra-wide-angle 3D LiDAR
- swarm coordination with Kepler humanoids.
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 270 kg |
|---|---|
| Dimensions | H 950 mm |
| Payload | 150 kg |
| Mobility | |
| Movement Type | Quadruped |
| Speed | 5.4 km/h |
| Environment | IPX5 whole machine / IP67 core components |
| Actuators | 12x planetary roller screw actuators (4 groups x 1 piece each for thigh/calf/hip) |
| Power | |
| Battery Life | 4.5-8 h |
| Sensing & Compute | |
| Sensors | ultra-wide-angle 3D LiDAR |
| Connectivity | Dual-band Wi-Fi 6, Bluetooth 5.2/4.2/2.1, 4G/5G module, optional Beidou+GPS+cellular tri-mode positioning |
| Software / AI | Graphical programming, autonomous path planning, intelligent follow, OTA upgrade, secondary development interface |
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 270 kg |
|---|---|
| Dimensions | H 950 mm |
| Payload | 150 kg |
| Mobility | |
| Movement Type | Quadruped |
| Speed | 5.4 km/h |
| Environment | IPX5 whole machine / IP67 core components |
| Actuators | 12x planetary roller screw actuators (4 groups x 1 piece each for thigh/calf/hip) |
| Power | |
| Battery Life | 4.5-8 h |
| Sensing & Compute | |
| Sensors | ultra-wide-angle 3D LiDAR |
| Connectivity | Dual-band Wi-Fi 6, Bluetooth 5.2/4.2/2.1, 4G/5G module, optional Beidou+GPS+cellular tri-mode positioning |
| Software / AI | Graphical programming, autonomous path planning, intelligent follow, OTA upgrade, secondary development interface |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Qilin?
The Kepler Qilin is a heavy-duty long-endurance quadruped built around the company's proprietary planetary roller screw actuators — 12 of them at 27,000 N peak thrust — giving a static payload capacity of over 600 kg and a rated dynamic payload of 150 kg on a 270 kg body.
Who makes the Qilin?
The Qilin is made by Kepler Robotics, a robotics company based in China.
How much does the Qilin cost?
Kepler Robotics has not publicly announced pricing for the Qilin. You can enquire through RobotAIGeek for current pricing.
What is the Qilin used for?
The Qilin is designed for delivery and patrol. It is used in defence, warehouse & logistics, manufacturing, and security & patrol settings.
What is the payload capacity of the Qilin?
The Qilin has a payload capacity of 150 kg.
How much does the Qilin weigh?
The Qilin weighs 270 kg.
How fast is the Qilin?
The Qilin can move at speeds of up to 5.4 km/h.
What is the battery life of the Qilin?
The Qilin runs for 4.5-8 h on a charge.
