DESCRIPTION
MOBOT AFL-CB20 is an Industrial-Robot from WObit. It is built for Intralogistics, Material-Handling, Pallet-Transportation. Key figures: 3410 kg, 900 min runtime, 2000 kg payload.
The MOBOT AFL-CB20 is WObit's autonomous counterbalance forklift for warehouses and production plants, carrying loads of up to 2,000 kg with fork width adjustable from 400 to 700 mm to suit different pallets and packaging. It can work up to 15 hours on a single charge of its LiFePO4 battery and reaches 1.5 m/s unloaded or 1.0 m/s loaded. It is controlled from a touch operator panel with an emergency switch and protected by a range of safety sensors including 2D and 3D laser scanners, and integrates with existing logistics infrastructure. The truck measures 2,839 x 1,161 x 2,250 mm and weighs up to 3,410 kg with batteries.
FEATURES
- Counterbalance design
- load up to 2,000 kg
- Fork width adjustable 400-700 mm
- Up to 15 h per charge
- LiFePO4 battery
- Speed 1.0 / 1.5 m/s (loaded / unloaded)
- Touch panel
- emergency switch
- 2D and 3D laser safety sensors
- Size 2,839 x 1,161 x 2,250 mm
- up to 3,410 kg
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 3410 kg |
|---|---|
| Dimensions | L 2.84 m × W 1.16 m × H 2.25 m |
| Payload | 2000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor warehouses and production plants |
| Power | |
| Battery Life | 900 min |
| Sensing & Compute | |
| Sensors | 2D laser scanners, 3D laser scanner |
| Connectivity | 2.4 GHz Wi-Fi; MOBOT RoutePlanner |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 3410 kg |
|---|---|
| Dimensions | L 2.84 m × W 1.16 m × H 2.25 m |
| Payload | 2000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor warehouses and production plants |
| Power | |
| Battery Life | 900 min |
| Sensing & Compute | |
| Sensors | 2D laser scanners, 3D laser scanner |
| Connectivity | 2.4 GHz Wi-Fi; MOBOT RoutePlanner |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the MOBOT AFL-CB20?
The MOBOT AFL-CB20 is WObit's autonomous counterbalance forklift for warehouses and production plants, carrying loads of up to 2,000 kg with fork width adjustable from 400 to 700 mm to suit different pallets and packaging.
Who makes the MOBOT AFL-CB20?
The MOBOT AFL-CB20 is made by WObit, a robotics company based in Poland.
How much does the MOBOT AFL-CB20 cost?
WObit has not publicly announced pricing for the MOBOT AFL-CB20. You can enquire through RobotAIGeek for current pricing.
What is the MOBOT AFL-CB20 used for?
The MOBOT AFL-CB20 is designed for intralogistics, material-handling, pallet-transportation, and transport. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the MOBOT AFL-CB20?
The MOBOT AFL-CB20 has a payload capacity of 2,000 kg.
How much does the MOBOT AFL-CB20 weigh?
The MOBOT AFL-CB20 weighs 3,410 kg.
How fast is the MOBOT AFL-CB20?
The MOBOT AFL-CB20 can move at speeds of up to 5.4 km/h.
What is the battery life of the MOBOT AFL-CB20?
The MOBOT AFL-CB20 runs for about 900 minutes on a charge.
