Guoxing RXR-M80D-15KT

Shandong Guoxing Intelligent Technology

Mobile-Robots China

ChinaReleased

★Not rated yet

Compare

Sources:

gxsuprobot.com

Industries:

Energy Manufacturing Security & Patrol

Uses:

Inspection MonitoringFires over soft, muddy or collapsed groundoff-road fire attackindustrial fire response

Price:

Not announced

DESCRIPTION

Guoxing RXR-M80D-15KT is a Mobile-Robots from Shandong Guoxing Intelligent Technology. It is built for Inspection, Monitoring, Fires over soft, muddy or collapsed ground. Key figures: 470 kg, 180 min runtime.

The RXR-M80D-15KT is the machine Guoxing points at ground that will not take a wheel. Its 150 mm flexible all-terrain crawler track is built for soft and muddy conditions, and the chassis sits over 155 mm clear, which together with double-belt water supply and in-situ steering — the turning radius is essentially zero, so it pivots on the spot — makes it usable in collapsed or unmade terrain. It runs on a lithium battery rather than a diesel engine, which keeps it quiet and emission-free indoors, at the cost of endurance: three hours against the five of its mains-cooled siblings. The 80 L/s water cannon rotates and tilts through a full 90 degrees of elevation and reaches beyond 80 metres, with water-curtain spray cooling for self-protection in high heat. At about 470 kg it climbs 40 degrees, which is the steepest slope figure of any tracked machine in the catalogue.

FEATURES

All-terrain crawler track 150 mm wide and flexible, suited to soft and muddy ground
Under 1650 x 950 x 1300 mm at about 470 kg
Maximum climbing of 40 degrees, the steepest of the tracked firefighting range
Chassis height exceeding 155 mm for strong climbing and obstacle crossing
In-situ steering with an extremely small turning radius
Speed from 0 to 1.7 m/s
Lithium battery power with a working time of 3 hours or more
Fire water cannon at 80 L/s, rotating and tilting to extinguish in all directions, shooting range over 80 metres
Water cannon pitch angle from 0 to 90 degrees
Double-belt water supply for large flow rate
Traction force of 3 kN and maximum obstacle 220 mm when unloaded
Spray cooling water curtain for self-cooling in high temperature scenes
IP65 protection
remote distance 1000 m in good environment
able to tow two 80 mm water hoses 40 metres
Dual LED strong light and sound-and-light alarm

TECHNICAL SPECIFICATIONS

Verified

Physical
Weight	470 kg
Dimensions	L 1.65 m × W 950 mm × H 1.3 m
Mobility
Movement Type	Other
Speed	6.12 km/h
Environment	Soft, muddy and complex off-road fire ground; IP65
Actuators	Flexible 150 mm all-terrain crawler track with in-situ steering and a rotating, tilting 80 L/s water cannon
Power
Battery Life	≥3 h

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Verified

Physical
Weight	470 kg
Dimensions	L 1.65 m × W 950 mm × H 1.3 m
Mobility
Movement Type	Other
Speed	6.12 km/h
Environment	Soft, muddy and complex off-road fire ground; IP65
Actuators	Flexible 150 mm all-terrain crawler track with in-situ steering and a rotating, tilting 80 L/s water cannon
Power
Battery Life	≥3 h

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Guoxing RXR-M80D-15KT?

Who makes the Guoxing RXR-M80D-15KT?

The Guoxing RXR-M80D-15KT is made by Shandong Guoxing Intelligent Technology, a robotics company based in China.

How much does the Guoxing RXR-M80D-15KT cost?

Shandong Guoxing Intelligent Technology has not publicly announced pricing for the Guoxing RXR-M80D-15KT. You can enquire through RobotAIGeek for current pricing.

What is the Guoxing RXR-M80D-15KT used for?

The Guoxing RXR-M80D-15KT is designed for inspection, monitoring, fires over soft, muddy or collapsed ground, and off-road fire attack. It is used in energy, manufacturing, and security & patrol settings.
