GD3
DESCRIPTION
Good Robot (Shandong) Automation Equipment Co., Ltd. builds the GD series of six-axis collaborative robot arms for industrial handling, assembly and machine tending. The series spans three payloads - the 3 kg GD3, the 5 kg GD5 and the 10 kg GD10 - sharing a common control platform and a lightweight aluminium construction with integrated joint modules. The GD3 is the smallest arm in the series, rated to carry 3 kg with a 620 mm reach and weighing 16.5 kg. Good Robot quotes a repeatability of +/-0.03 mm, a DC48V supply and a 150 mm tool flange with four M6 fixings.
FEATURES
- Payload: 3 kg
- Reach: 620 mm
- Robot mass: 16.5 kg
- 6 axes (6 degrees of freedom)
- Repeatability: +/-0.03 mm
- Supply voltage: DC48V
- Base mounting: 150 mm diameter, 4 x M6
- Body dimensions approx. 650 x 480 x 420 mm
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 16.5 kg |
|---|---|
| Payload | 3 kg |
| Reach | 620 mm |
| Repeatability | ±0.03 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
| Manipulation | Mid |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 16.5 kg |
|---|---|
| Payload | 3 kg |
| Reach | 620 mm |
| Repeatability | ±0.03 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
| Manipulation | Mid |
Images
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the GD3?
Good Robot (Shandong) Automation Equipment Co., Ltd. builds the GD series of six-axis collaborative robot arms for industrial handling, assembly and machine tending.
Who makes the GD3?
The GD3 is made by Good Robot (Shandong) Automation Equipment Co., Ltd., a robotics company based in China.
How much does the GD3 cost?
Good Robot (Shandong) Automation Equipment Co., Ltd. has not publicly announced pricing for the GD3. You can enquire through RobotAIGeek for current pricing.
What is the GD3 used for?
The GD3 is designed for assembly. It is used in manufacturing settings.
What is the payload capacity of the GD3?
The GD3 has a payload capacity of 3 kg and a reach of 620 mm.
How much does the GD3 weigh?
The GD3 weighs 16.5 kg.
How many degrees of freedom does the GD3 have?
The GD3 has 6 degrees of freedom.
