DESCRIPTION
FP200 is an Industrial-Robot from Zhejiang HuaRay Technology. It is built for Heavy-Load-Transportation, Intralogistics, Lifting. Key figures: 3100 kg, 480 min runtime, 2000 kg payload.
FP200 is the 2-tonne version of iRAYPLE's FP150 stacking forklift AMR: a 3.1-tonne truck with a 3 m lift and a 3.45 m minimum pick-up aisle. It navigates by Laser, reaches 1.5 m/s empty and 1.0 m/s loaded, stops within ±10 mm and runs 6-8 h per charge (charging: manual/auto). It talks to iRAYPLE's robot control and scheduling system over WiFi / 5G (optional).
FEATURES
- Rated load 2000 kg
- machine weight 3100 kg
- 2942 mm×1112 mm×2259 mm
- Max. speed 1.5 m/s empty, 1.0 m/s loaded
- Navigation: Laser
- drive: Single steering wheel drive
- Height of Rear Fork above Ground after Lifting: 3000mm
- Load Center Distance: 500mm
- Minimum Pickup Channel: 3450mm
- Fork Size: 1070mm×100mm×40mm
- Turning Radius: 1760mm
- Stopping accuracy (no load): ±10 mm
- Climbing Ability: 3° (5%)
- Autonomous pallet recognition
- Charging Mode: Manual/Auto
- Communication Mode: WiFi / 5G (optional)
- Operating time 6-8h
- charging 2 h
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 3100 kg |
|---|---|
| Dimensions | L 2.94 m × W 1.11 m × H 2.26 m |
| Payload | 2000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Factories and warehouses (indoor, 0-40 C) |
| Power | |
| Battery Life | 480 min |
| Charging Type | Manual/Auto |
| Sensing & Compute | |
| Sensors | laser navigation/obstacle-avoidance scanners, vision obstacle avoidance, collision bumpers, pallet presence sensors |
| Connectivity | WiFi / 5G (optional) |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 3100 kg |
|---|---|
| Dimensions | L 2.94 m × W 1.11 m × H 2.26 m |
| Payload | 2000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Factories and warehouses (indoor, 0-40 C) |
| Power | |
| Battery Life | 480 min |
| Charging Type | Manual/Auto |
| Sensing & Compute | |
| Sensors | laser navigation/obstacle-avoidance scanners, vision obstacle avoidance, collision bumpers, pallet presence sensors |
| Connectivity | WiFi / 5G (optional) |
Images
martti
martti
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the FP200?
FP200 is the 2-tonne version of iRAYPLE's FP150 stacking forklift AMR: a 3.1-tonne truck with a 3 m lift and a 3.45 m minimum pick-up aisle. It navigates by Laser, reaches 1.5 m/s empty and 1.0 m/s loaded, stops within ±10 mm and runs 6-8 h per charge (charging: manual/auto).
Who makes the FP200?
The FP200 is made by Zhejiang HuaRay Technology, a robotics company based in China.
How much does the FP200 cost?
Zhejiang HuaRay Technology has not publicly announced pricing for the FP200. You can enquire through RobotAIGeek for current pricing.
What is the FP200 used for?
The FP200 is designed for heavy-load-transportation, intralogistics, lifting, and loading. It is used in automotive, electronics, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the FP200?
The FP200 has a payload capacity of 2,000 kg.
How much does the FP200 weigh?
The FP200 weighs 3,100 kg.
How fast is the FP200?
The FP200 can move at speeds of up to 5.4 km/h.
What is the battery life of the FP200?
The FP200 runs for about 480 minutes on a charge.
