DESCRIPTION
The MV-10 is the heavy end of the DOK-ING range: 20,920 kg, 8,075 mm long, 2,970 mm wide and 2,330 mm tall, built for ground where the lighter machines would be outmatched — anti-tank mines and heavy unexploded ordnance. A Caterpillar C18 delivers 571 kW (766 HP) and 3,495 Nm at 1,400 rpm, consuming 25 to 50 litres an hour. The vehicle keeps the family's characteristics: remote control with the operator clear of the danger area, full body protection, day and night operation, on and off-road mobility, and mapping of the ground it has covered. It is transportable by air and road despite its mass, and takes the same approach to interchangeable clearance tools as the rest of the MV series.
FEATURES
- Heavy remote-controlled demining vehicle for anti-tank mines and heavy UXO
- Dimensions 8,075 x 2,970 x 2,330 mm
- Weight approx. 20,920 kg
- Caterpillar C18 engine
- Engine power 571 kW / 766 HP
- torque 3,495 Nm at 1,400 rpm
- Fuel consumption 25 to 50 litres per hour
- Full body protection
- Air and road transportable
- Day and night operation
- multi-mission capability
- area mapping
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 20920 kg |
|---|---|
| Dimensions | L 8.07 m × W 2.97 m × H 2.33 m |
| Mobility | |
| Movement Type | Wheeled |
| Environment | Minefields, disaster sites and contaminated ground; on and off-road, operator at a distance |
| Sensing & Compute | |
| Sensors | cameras for day and night operation, situational-awareness and mapping sensors |
| Software / AI | Remote control with area mapping and situational awareness |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 20920 kg |
|---|---|
| Dimensions | L 8.07 m × W 2.97 m × H 2.33 m |
| Mobility | |
| Movement Type | Wheeled |
| Environment | Minefields, disaster sites and contaminated ground; on and off-road, operator at a distance |
| Sensing & Compute | |
| Sensors | cameras for day and night operation, situational-awareness and mapping sensors |
| Software / AI | Remote control with area mapping and situational awareness |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the DOK-ING MV-10?
The MV-10 is the heavy end of the DOK-ING range: 20,920 kg, 8,075 mm long, 2,970 mm wide and 2,330 mm tall, built for ground where the lighter machines would be outmatched — anti-tank mines and heavy unexploded ordnance.
Who makes the DOK-ING MV-10?
The DOK-ING MV-10 is made by DOK-ING, a robotics company based in Croatia.
How much does the DOK-ING MV-10 cost?
DOK-ING has not publicly announced pricing for the DOK-ING MV-10. You can enquire through RobotAIGeek for current pricing.
What is the DOK-ING MV-10 used for?
The DOK-ING MV-10 is designed for reconnaissance, rescue, security, and inspection. It is used in defence, government, and construction settings.
How much does the DOK-ING MV-10 weigh?
The DOK-ING MV-10 weighs 20,920 kg.
