DESCRIPTION
Bluefin-9 is a Marine from Bluefin Robotics (General Dynamics). It is built for Research, Security, Inspection. Key figures: 70 kg, 480 min runtime.
Bluefin-9 is a two-man-portable autonomous UUV from General Dynamics Mission Systems / Bluefin Robotics. It integrates Sonardyne Solstice multi-aperture sonar, HD camera, and environmental sensors for high-resolution littoral surveys with rapid battery/RDSM swap.
FEATURES
- ~9.375×10.375 in cross-section
- Length 95.2 in (241.8 cm)
- 155 lb (70 kg)
- Depth 656 ft (200 m)
- Endurance 8 h @ 3 kt
- Sustained speed up to 6 knots
- 1.9 kWh swappable Li-ion
- Solstice MAS 200 m swath / 0.15° along-track
- Nav ≤0.3% DT CEP50
- 1 TB RDSM + HD camera
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 70 kg |
|---|---|
| Dimensions | L 2.42 m × W 238 mm × H 264 mm |
| Mobility | |
| Movement Type | Aquatic |
| Speed | 11.11 km/h |
| Power | |
| Battery Life | 480 min |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 70 kg |
|---|---|
| Dimensions | L 2.42 m × W 238 mm × H 264 mm |
| Mobility | |
| Movement Type | Aquatic |
| Speed | 11.11 km/h |
| Power | |
| Battery Life | 480 min |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Bluefin-9?
Bluefin-9 is a two-man-portable autonomous UUV from General Dynamics Mission Systems / Bluefin Robotics. It integrates Sonardyne Solstice multi-aperture sonar, HD camera, and environmental sensors for high-resolution littoral surveys with rapid battery/RDSM swap.
Who makes the Bluefin-9?
The Bluefin-9 is made by Bluefin Robotics (General Dynamics), a robotics company based in United States.
How much does the Bluefin-9 cost?
Bluefin Robotics (General Dynamics) has not publicly announced pricing for the Bluefin-9. You can enquire through RobotAIGeek for current pricing.
What is the Bluefin-9 used for?
The Bluefin-9 is designed for research, security, inspection, and monitoring. It is used in research settings.
How much does the Bluefin-9 weigh?
The Bluefin-9 weighs 70 kg.
How fast is the Bluefin-9?
The Bluefin-9 can move at speeds of up to 11.11 km/h.
What is the battery life of the Bluefin-9?
The Bluefin-9 runs for about 480 minutes on a charge.
