DESCRIPTION
The 30 t Backpack Heavy Duty AGV is a Backpack Heavy-duty AGV built by Lonyu AGV, rated to carry 30 t. Lonyu designates it LY-AU-30T-40B. It has a body measuring 5230 mm long, 1800 mm wide and 550 mm high and an unladen mass of 5 t. Mechanically, the chassis uses tubesheet; the drive layout is 4-drive; suspension is hydraulic. Drive is superdrive. It navigates by magnetic stripe, is commanded by manual remote + automatic operation. For power and motion, it runs at 48V.
FEATURES
- Rated load: 30 t
- Unladen mass: 5 t
- Body dimensions: 5230 x 1800 x 550 mm
- Chassis: Tubesheet
- Drive wheels: 4-Drive
- Drive type: Superdrive
- Navigation: Magnetic Stripe
- Control: Manual Remote + Automatic Operation
- Voltage: 48V
- Suspension: Hydraulic
- Turning radius: 1530mm
- Castors: 0
- Linkage mode: Single AGV
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 5000 kg |
|---|---|
| Dimensions | L 5.23 m × W 1.8 m × H 550 mm |
| Payload | 30000 kg |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 5000 kg |
|---|---|
| Dimensions | L 5.23 m × W 1.8 m × H 550 mm |
| Payload | 30000 kg |
Images
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the 30 t Backpack Heavy Duty AGV?
The 30 t Backpack Heavy Duty AGV is a Backpack Heavy-duty AGV built by Lonyu AGV, rated to carry 30 t. Lonyu designates it LY-AU-30T-40B. It has a body measuring 5230 mm long, 1800 mm wide and 550 mm high and an unladen mass of 5 t.
Who makes the 30 t Backpack Heavy Duty AGV?
The 30 t Backpack Heavy Duty AGV is made by Lonyu Agv.
How much does the 30 t Backpack Heavy Duty AGV cost?
Lonyu Agv has not publicly announced pricing for the 30 t Backpack Heavy Duty AGV. You can enquire through RobotAIGeek for current pricing.
What is the 30 t Backpack Heavy Duty AGV used for?
The 30 t Backpack Heavy Duty AGV is designed for transport.
What is the payload capacity of the 30 t Backpack Heavy Duty AGV?
The 30 t Backpack Heavy Duty AGV has a payload capacity of 30,000 kg.
How much does the 30 t Backpack Heavy Duty AGV weigh?
The 30 t Backpack Heavy Duty AGV weighs 5,000 kg.
