描述
NaviGO是Muvro的Mobile-Robots。 面向載入中、物料搬運、托盤運輸設計。 關鍵數據：650 kg、續航 720 分鐘、負載 2000 kg。
NaviGO is Muvro's mother-child pallet shuttle for high-density automated pallet storage. A powered aisle cart, the mother shuttle, travels along the aisle carrying a battery-powered child shuttle, which drives into deep storage lanes to deposit or retrieve pallets. Vertical lifts called eLifts move pallets between levels, and buffer conveyors at each level let lifts and shuttles work in parallel. The mother shuttle runs at up to 3 m/s with 2,000 kg capacity and +/-1 mm positioning, while the child shuttle carries 500 kg at 1.1 m/s empty and 0.8 m/s loaded with +/-20 mm accuracy. The shuttle unit measures 2,400 x 1,450 x 600 mm and weighs 650 kg (750 kg for NaviGO-Pro). Child shuttles use 48 V LiFePO4 batteries of 24 or 48 Ah that charge from 10 to 90 percent in about an hour and give 12 hours of running time. Control is by a Siemens S7 PLC over Profinet, with Wenglor laser distance sensors, collision detection and emergency stops. Lanes reach about 45 m deep and racking can exceed 40 m in height, with 0.914 m shuttle aisles. A cold version works from -30 to +5 C. Muvro targets FMCG, e-commerce, cold storage, automotive, pharmaceutical and 3PL warehouses.
功能特色
- Mother-child pallet shuttle ASRS (NaviGO and NaviGO-Pro)
- Mother shuttle (aisle cart): max speed 3 m/s, 2,000 kg capacity, +/-1 mm positioning
- Child shuttle: 500 kg capacity, 1.1 m/s empty / 0.8 m/s loaded, +/-20 mm positioning
- eLift pallet lifter: 2,000 kg max load, 2 s lifting time
- Buffer conveyor at each level for parallel lift and shuttle operation
- Shuttle dimensions 2,400 x 1,450 x 600 mm
- self weight 650 / 750 kg
- Pallet sizes: width 1,220 mm, length 800/1,000/1,200 mm, height 150 mm
- LIFO/FIFO load management
- Child battery: LiFePO4 48 V 24 Ah / 48 V 48 Ah
- Charging 10-90% in 1 h at charging station
- external charger 100-230 V AC in, 48 V max 12 A out
- Running time 12 h
- Motors: pallet lifting 750 W / 1.5 kW
- child movement 750 W / 1 kW
- mother movement 1.5 / 3 kW
- pallet transfer 500 W / 1.5 kW
- System power 440 V
- Operating temperature +5 to +50 C
- cold version -30 to +5 C
- humidity 10-95% non-condensing
- Wenglor P1KY101 laser distance sensors
- Siemens S7-1200 PLC (CPU 1513-1PM listed), Profinet
- Single and dual command cycles
- barcode tracking
- API and WMS integration
- Emergency stop circuits and collision detection / anti-crash logic
- Lanes up to about 45 m deep
- racking above 40 m
- shuttle aisle 0.914 m
- ISO 9001:2015 production
- architecture based on CE safety directives
技術規格
已驗證| 物理參數 | |
| 重量 | 650 kg |
|---|---|
| 外形尺寸 | L 2.4 m × W 1.45 m × H 600 mm |
| 負載 | 2000 kg |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 10.8 km/h |
| 作業環境 | Ambient (+5 to +50 C) and cold / deep-freeze (-30 to +5 C) warehouses, -30°C to 50°C |
| 電源與續航 | |
| 續航時間 | 720 min |
| 感知與計算 | |
| 感測器 | Wenglor P1KY101 laser distance sensors, Collision detection, Barcode tracking |
| 連線方式 | Profinet; API integration with WMS/ERP |
| 軟體 / AI | Muvro WMS / WCS |
機器人論壇
正在載入論壇...
技術規格
已驗證| 物理參數 | |
| 重量 | 650 kg |
|---|---|
| 外形尺寸 | L 2.4 m × W 1.45 m × H 600 mm |
| 負載 | 2000 kg |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 10.8 km/h |
| 作業環境 | Ambient (+5 to +50 C) and cold / deep-freeze (-30 to +5 C) warehouses, -30°C to 50°C |
| 電源與續航 | |
| 續航時間 | 720 min |
| 感知與計算 | |
| 感測器 | Wenglor P1KY101 laser distance sensors, Collision detection, Barcode tracking |
| 連線方式 | Profinet; API integration with WMS/ERP |
| 軟體 / AI | Muvro WMS / WCS |
圖片
martti
martti
martti
martti圖片貢獻
影片
機器人論壇
正在載入論壇...
評分
常見問題
What is the NaviGO?
NaviGO is Muvro's mother-child pallet shuttle for high-density automated pallet storage. A powered aisle cart, the mother shuttle, travels along the aisle carrying a battery-powered child shuttle, which drives into deep storage lanes to deposit or retrieve pallets.
Who makes the NaviGO?
The NaviGO is made by Muvro, a robotics company based in India.
How much does the NaviGO cost?
Muvro has not publicly announced pricing for the NaviGO. You can enquire through RobotAIGeek for current pricing.
What is the NaviGO used for?
The NaviGO is designed for 載入中, 物料搬運, 托盤運輸, and 卸貨. It is used in 汽車, 醫療保健, 物流, and 製造業 settings.
What is the payload capacity of the NaviGO?
The NaviGO has a payload capacity of 2,000 kg.
How much does the NaviGO weigh?
The NaviGO weighs 650 kg.
How fast is the NaviGO?
The NaviGO can move at speeds of up to 10.8 km/h.
What is the battery life of the NaviGO?
The NaviGO runs for about 720 minutes on a charge.
