DESCRIPTION
TransitX T1 is an Exoskeleton from TransitX. It is built for Assistance, Rehabilitation, Helping. Key figures: 60 kg, 100 kg payload.
The TransitX T1 is by far the most ambitious machine in the TransitX range and the only one that is not a wearable aid: a lower-limb mech, roughly 120 cm tall, that a person with mobility impairments sits in and travels on. Twelve servo motors drive it, and TransitX states the goal plainly - a machine that walks, runs, jumps and self-balances. It weighs 60 kg and carries up to 100 kg, with the sub-0.05-second mechanical response and adaptive force output shared with the S1 walking aid: modular adjustment points fit 95 percent of body types, and the system detects leg-motion state and adjusts output to it. TransitX frames the project as harnessing China's industrial base to make a lower-limb exoskeleton affordable, committing to make each iteration lighter and cheaper. It is IP54 rated. **Not yet on sale** - the catalogue states it is expected to launch by the end of 2026, so it is recorded here as a prototype.
FEATURES
- Twelve servo motors driving the lower limbs
- Designed to walk, run, jump and self-balance
- 60 kg system weight with a 100 kg maximum load
- About 120 cm tall
- Mechanical response under 0.05 seconds
- Adaptive output that detects and adjusts to leg-motion state
- Modular adjustment points fitting 95 percent of body types
- IP54 water and dust protection
- Aimed at affordability through Chinese industrial manufacturing
- Expected to launch by the end of 2026 - not yet on sale
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 60 kg |
|---|---|
| Dimensions | H 1.2 m |
| Payload | 100 kg |
| Mobility | |
| Movement Type | Bipedal |
| Manipulation | Low |
| Actuators | 12 servo motors |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 60 kg |
|---|---|
| Dimensions | H 1.2 m |
| Payload | 100 kg |
| Mobility | |
| Movement Type | Bipedal |
| Manipulation | Low |
| Actuators | 12 servo motors |
Images
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the TransitX T1?
The TransitX T1 is by far the most ambitious machine in the TransitX range and the only one that is not a wearable aid: a lower-limb mech, roughly 120 cm tall, that a person with mobility impairments sits in and travels on.
Who makes the TransitX T1?
The TransitX T1 is made by TransitX, a robotics company based in China.
How much does the TransitX T1 cost?
TransitX has not publicly announced pricing for the TransitX T1. You can enquire through RobotAIGeek for current pricing.
What is the TransitX T1 used for?
The TransitX T1 is designed for assistance, rehabilitation, and helping. It is used in consumer, research, and healthcare settings.
What is the payload capacity of the TransitX T1?
The TransitX T1 has a payload capacity of 100 kg.
How much does the TransitX T1 weigh?
The TransitX T1 weighs 60 kg.
