DESCRIPTION
Thor is a Mobile-Robots from Esatroll. It is built for Material-Handling, Transport, Counterbalanced LGV that moves pallets, coils and containers up to 3 tonnes. Key figures: 480 min runtime, 3000 kg payload, released 2018.
Thor is a medium-size counterbalanced general-purpose LGV for indoor and outdoor use with a payload of up to 3,000 kg at a 600 mm load centre. It can carry forks, side telescopic forks or hydraulic clamps for coils and containers, and Esatroll's 2018 launch post adds a front ram for coils, at least 8 hours per battery with battery swap or sliding-contact automatic charging, touch-screen or tablet control, and operation in hostile environments, at high temperatures or down to -30 C. Like Esatroll's other vehicles it is designed and built in-house in Switzerland and adapted to each customer's plant, and it can be run by Esatroll's customised supervisor, which takes calls from workstations, assigns vehicles, manages right of way and load delivery and logs activity.
FEATURES
- Up to 3,000 kg at 600 mm load centre
- Forks, side telescopic forks or hydraulic clamps
- Indoor and outdoor
- Front and rear laser scanners
- front and side bumpers
- At least 8 h per battery
- automatic charging option
- Up to 1.5 m/s
- 5 kW
- 48 V
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.94 m × W 1.61 m |
|---|---|
| Payload | 3000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor and outdoor plants and yards, down to -30 C |
| Power | |
| Battery Life | 480 min |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Dimensions | L 1.94 m × W 1.61 m |
|---|---|
| Payload | 3000 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.4 km/h |
| Environment | Indoor and outdoor plants and yards, down to -30 C |
| Power | |
| Battery Life | 480 min |
Images



Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Thor?
Thor is a medium-size counterbalanced general-purpose LGV for indoor and outdoor use with a payload of up to 3,000 kg at a 600 mm load centre.
Who makes the Thor?
The Thor is made by Esatroll, a robotics company based in Switzerland.
How much does the Thor cost?
Esatroll has not publicly announced pricing for the Thor. You can enquire through RobotAIGeek for current pricing.
What is the Thor used for?
The Thor is designed for material-handling, transport, and counterbalanced lgv that moves pallets, coils and containers up to 3 tonnes. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the Thor?
The Thor has a payload capacity of 3,000 kg.
How fast is the Thor?
The Thor can move at speeds of up to 5.4 km/h.
What is the battery life of the Thor?
The Thor runs for about 480 minutes on a charge.
When was the Thor released?
The Thor was released in 2018.
