DESCRIPTION
SAFELOG S3 tow is a Mobile-Robots from SAFELOG. It is built for Intralogistics, Material-Handling, Transport. Key figures: 150 kg, 90 min runtime, 500 kg payload.
The S3 tow is the towing version of SAFELOG's compact S3 transport robot, built to move trolleys and trailers of up to 500 kg. An electric lifting bolt with 55 mm travel picks up and releases the trailer automatically, and like the rest of the S3 series it turns on the spot within less than 90 cm, is protected by a safety laser scanner and communicates over Wi-Fi with other robots and peripheral systems. Per its datasheet it measures 770 x 450 x 220 mm, weighs 150 kg, drives at up to 1.0 m/s loaded (1.6 m/s empty) and runs about 1.5 hours under load on a 24 V 21 Ah LiFePO4 battery charged inductively in about 20 minutes.
FEATURES
- Tows trolleys and trailers up to 500 kg
- Electric lifting bolt (55 mm travel) picks up and releases the trailer automatically
- Turns on the spot in under 90 cm
- turning radius 0.8 m
- Speed 0.02-1.0 m/s (1.6 m/s empty)
- Localization: magnetic track, RFID, odometry, inductive sensor
- LiDAR or 2D camera optional
- LiFePO4 24 V 21 Ah
- 20 min charge
- 1.5 h with load
- Size 770 x 450 x 220 mm
- 150 kg
- CE, FCC, IP54
- Agent-based swarm control (SAFELOG IntelliAgent) over Wi-Fi - no central control station needed
- VDA 5050-ready for third-party fleet managers
- Inductive in-process charging
- LiFePO4 batteries
- Operating range +5 to +35 C
- VDI 2510 floors
- 24/7 operation
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 150 kg |
|---|---|
| Dimensions | L 770 mm × W 450 mm × H 220 mm |
| Payload | 500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Indoor production and warehouse floors (+5 to 35 C, VDI 2510) |
| Power | |
| Battery Life | 90 min |
| Sensing & Compute | |
| Sensors | safety laser scanner, RFID / grid-code / magnetic-track sensors |
| Connectivity | Wi-Fi; VDA 5050 |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 150 kg |
|---|---|
| Dimensions | L 770 mm × W 450 mm × H 220 mm |
| Payload | 500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Indoor production and warehouse floors (+5 to 35 C, VDI 2510) |
| Power | |
| Battery Life | 90 min |
| Sensing & Compute | |
| Sensors | safety laser scanner, RFID / grid-code / magnetic-track sensors |
| Connectivity | Wi-Fi; VDA 5050 |
Images
martti
martti
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the SAFELOG S3 tow?
The S3 tow is the towing version of SAFELOG's compact S3 transport robot, built to move trolleys and trailers of up to 500 kg. An electric lifting bolt with 55 mm travel picks up and releases the trailer automatically, and like the rest of the S3 series it turns on the spot within less than 90 cm, is protected by a saf…
Who makes the SAFELOG S3 tow?
The SAFELOG S3 tow is made by SAFELOG, a robotics company based in Germany.
How much does the SAFELOG S3 tow cost?
SAFELOG has not publicly announced pricing for the SAFELOG S3 tow. You can enquire through RobotAIGeek for current pricing.
What is the SAFELOG S3 tow used for?
The SAFELOG S3 tow is designed for intralogistics, material-handling, transport, and intralogistics. It is used in automotive, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the SAFELOG S3 tow?
The SAFELOG S3 tow has a payload capacity of 500 kg.
How much does the SAFELOG S3 tow weigh?
The SAFELOG S3 tow weighs 150 kg.
How fast is the SAFELOG S3 tow?
The SAFELOG S3 tow can move at speeds of up to 5.76 km/h.
What is the battery life of the SAFELOG S3 tow?
The SAFELOG S3 tow runs for about 90 minutes on a charge.
