DESCRIPTION
SAFELOG M4 tow is a Mobile-Robots from SAFELOG. It is built for Intralogistics, Material-Handling, Transport. Key figures: 235 kg, 72 min runtime, 1500 kg payload.
The M4 tow is the tugger version of SAFELOG's M4 series, built to move trolleys and trailers with loads of up to 1,500 kg. An electric lifting pin and snap latch - optionally combined with an RFID reader or light buttons - pick up and drop off the trailer automatically, and its brushless servo motor gives it high starting torque. Per its datasheet it measures 1,460 x 450 x 220 mm, weighs 235 kg, turns in a 1 m radius, drives at up to 1.0 m/s loaded (1.6 m/s empty) and runs about 1.2 hours under load on the standard 24 V 21 Ah LiFePO4 battery, extendable with up to four packs.
FEATURES
- Tows trolleys and trailers up to 1,500 kg
- Electric lifting pin (55 mm travel) and snap latch
- optional RFID reader or light buttons for automatic pickup and delivery
- Brushless servo motor
- turning radius 1 m
- Speed 0.02-1.0 m/s (1.6 m/s empty)
- Localization: magnetic track, RFID, odometry
- LiDAR or 2D camera optional
- LiFePO4 24 V 21 Ah standard (up to 84 Ah)
- 20 min charge
- Size 1,460 x 450 x 220 mm
- 235 kg
- CE, FCC, IP54
- Agent-based swarm control (SAFELOG IntelliAgent) over Wi-Fi - no central control station needed
- VDA 5050-ready for third-party fleet managers
- Inductive in-process charging
- LiFePO4 batteries
- Operating range +5 to +35 C
- VDI 2510 floors
- 24/7 operation
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 235 kg |
|---|---|
| Dimensions | L 1.46 m × W 450 mm × H 220 mm |
| Payload | 1500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Indoor production and warehouse floors (+5 to 35 C, VDI 2510) |
| Power | |
| Battery Life | 72 min |
| Sensing & Compute | |
| Sensors | safety laser scanner, RFID / grid-code / magnetic-track sensors |
| Connectivity | Wi-Fi; VDA 5050 |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 235 kg |
|---|---|
| Dimensions | L 1.46 m × W 450 mm × H 220 mm |
| Payload | 1500 kg |
| Mobility | |
| Movement Type | Wheeled |
| Speed | 5.76 km/h |
| Environment | Indoor production and warehouse floors (+5 to 35 C, VDI 2510) |
| Power | |
| Battery Life | 72 min |
| Sensing & Compute | |
| Sensors | safety laser scanner, RFID / grid-code / magnetic-track sensors |
| Connectivity | Wi-Fi; VDA 5050 |
Images
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the SAFELOG M4 tow?
The M4 tow is the tugger version of SAFELOG's M4 series, built to move trolleys and trailers with loads of up to 1,500 kg. An electric lifting pin and snap latch - optionally combined with an RFID reader or light buttons - pick up and drop off the trailer automatically, and its brushless servo motor gives it high start…
Who makes the SAFELOG M4 tow?
The SAFELOG M4 tow is made by SAFELOG, a robotics company based in Germany.
How much does the SAFELOG M4 tow cost?
SAFELOG has not publicly announced pricing for the SAFELOG M4 tow. You can enquire through RobotAIGeek for current pricing.
What is the SAFELOG M4 tow used for?
The SAFELOG M4 tow is designed for intralogistics, material-handling, transport, and intralogistics. It is used in automotive, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the SAFELOG M4 tow?
The SAFELOG M4 tow has a payload capacity of 1,500 kg.
How much does the SAFELOG M4 tow weigh?
The SAFELOG M4 tow weighs 235 kg.
How fast is the SAFELOG M4 tow?
The SAFELOG M4 tow can move at speeds of up to 5.76 km/h.
What is the battery life of the SAFELOG M4 tow?
The SAFELOG M4 tow runs for about 72 minutes on a charge.
