DESCRIPTION
RB10-1300 is an Industrial-Robot from Rainbow Robotics. It is built for Assembly, palletizing, Pick-and-place. Key figures: 37.1 kg, 10 kg payload, 1300 mm reach, 6 degrees of freedom.
The RB10-1300 is a Rainbow Robotics collaborative robot arm with a 10 kg payload and 1300 mm reach, built for safe human-robot cooperation on industrial tasks such as packaging, welding, assembly, and inspection.
FEATURES
- In-house engineered high-performance collaborative arm
- globally certified safety (NRTL, CE, KCs / TÜV SÜD — ISO 13849-1 Cat.3 PL d, ISO 10218-1, ISO/TS 15066)
- ±0.05 mm repeatability
- IP-rated operating environment per model
- M8 tool flange
- 5 m robot-arm cable. Model RB10-1300: payload 10 kg, reach 1300 mm, arm weight 37.1 kg, footprint ∅ 196 mm, operating environment IP66 / 0-50 °C.
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 37.1 kg |
|---|---|
| Payload | 10 kg |
| Reach | 1.3 m |
| Repeatability | ±0.05 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
Videos
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 37.1 kg |
|---|---|
| Payload | 10 kg |
| Reach | 1.3 m |
| Repeatability | ±0.05 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
Images
martti
Image Contributions
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the RB10-1300?
The RB10-1300 is a Rainbow Robotics collaborative robot arm with a 10 kg payload and 1300 mm reach, built for safe human-robot cooperation on industrial tasks such as packaging, welding, assembly, and inspection.
Who makes the RB10-1300?
The RB10-1300 is made by Rainbow Robotics, a robotics company based in South Korea.
How much does the RB10-1300 cost?
Rainbow Robotics has not publicly announced pricing for the RB10-1300. You can enquire through RobotAIGeek for current pricing.
What is the RB10-1300 used for?
The RB10-1300 is designed for assembly, palletizing, pick-and-place, and welding. It is used in manufacturing settings.
What is the payload capacity of the RB10-1300?
The RB10-1300 has a payload capacity of 10 kg and a reach of 1.3 m.
How much does the RB10-1300 weigh?
The RB10-1300 weighs 37.1 kg.
How many degrees of freedom does the RB10-1300 have?
The RB10-1300 has 6 degrees of freedom.
