Peitian AIR6SC-600

Peitian Robot

Industrial-Robot China

ChinaReleased

★Not rated yet

Compare

Sources:

cdn.robotaigeek.com

Industries:

Research Manufacturing

Uses:

Assembly Pick-and-placeElectronics assemblypick-and-placemachine tool loading and unloadingpackaging

Price:

Not announced

DESCRIPTION

Peitian AIR6SC-600 is an Industrial-Robot from Peitian Robot. It is built for Assembly, Pick-and-place, Electronics assembly. Key figures: 20.1 kg, 2 kg payload, 600 mm reach, 4 degrees of freedom.

The AIR6SC-600 is a four-axis SCARA from Peitian's AIR range, reaching 600 mm and rated for 2 kg with a 6 kg maximum. SCARA geometry trades the full articulation of a six-axis arm for stiffness in the vertical direction and speed in the horizontal plane, which is why this class dominates electronics assembly, pick-and-place and machine tending rather than welding or finishing. At 20.1 kg the arm itself is light enough to mount on a bench or a line frame. Peitian pairs it with its own inCube2S-6 controller cabinet. Ingress protection is IP20.

FEATURES

SCARA four-axis industrial robot arm
Rated payload 2 kg with a maximum payload of 6 kg
Axis 3 vertical stroke available in 200 / 300 / 400 / 600 mm options
Maximum reach 600 mm
Manipulator weight 20.1 kg
Ingress protection IP20
Mounting: Floor
Compatible controller cabinets: inCube2S-6
Working range Axis 1 -137°/+137°
Axis 2 -134°/+134°
Axis 4 -150°/+150°
Axis 4 wrist -150°/+150°
Axis 5 bend -360°/+360°
Axis 6 turn -360°/+360°
Rotation rate combined Axis 1 and Axis 2 400°/s
Axis 3 vertical 400°/s
Axis 4 650°/s
Axis 4 wrist 650°/s
Axis 5 bend 2300°/s
Axis 6 turn 2300°/s
Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
No corrosive, flammable or explosive gases permitted in the operating environment

TECHNICAL SPECIFICATIONS

Physical
Weight	20.1 kg
Payload	2 kg
Reach	600 mm
Mobility
Movement Type	Stationary
Degrees of Freedom	4
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	4-axis SCARA four-axis manipulator, mounted Floor
Sensing & Compute
Software / AI	Driven by Peitian inCube2S-6 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Physical
Weight	20.1 kg
Payload	2 kg
Reach	600 mm
Mobility
Movement Type	Stationary
Degrees of Freedom	4
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	4-axis SCARA four-axis manipulator, mounted Floor
Sensing & Compute
Software / AI	Driven by Peitian inCube2S-6 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Peitian AIR6SC-600?

Who makes the Peitian AIR6SC-600?

The Peitian AIR6SC-600 is made by Peitian Robot, a robotics company based in China.

How much does the Peitian AIR6SC-600 cost?

Peitian Robot has not publicly announced pricing for the Peitian AIR6SC-600. You can enquire through RobotAIGeek for current pricing.

What is the Peitian AIR6SC-600 used for?

The Peitian AIR6SC-600 is designed for assembly, pick-and-place, electronics assembly, and pick-and-place. It is used in research and manufacturing settings.
